Summary of Contents for Wharfedale Pro SLIM BASS 8
- Page 1 SLIM BASS 8...
-
Page 2: Important Safety Information
USER MANUAL: SLIM BASS 8 IMPORTANT SAFETY INFORMATION CAUTION: These servicing instructions are for use by qualified CAUTION! service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the RISK OF ELECTRIC SHOCK DO NOT OPEN operating instructions unless you are qualified to do so. -
Page 3: Installation
Positioning the Subwoofer SLIM BASS 8 is designed for placement in tight spaces. For instance, close to your chair or sofa (or underneath if space allows). The unit may be placed almost anywhere in the room, we also recommend that it be placed in front of the listener and as central to the listening position as possible. - Page 4 Consult your dealer if in doubt. CONNECTING THE SUBWOOFER TO THE SYSTEM Control Panel of the SLIM BASS 8 SLIM BASS 8 Active Subwoofer...
-
Page 5: Operating Your Subwoofer
Initial Settings Volume Control: Set the subwoofer volume control to the minimum before proceeding. Crossover Control: Adjust frequency to integrate SLIM BASS 8 subwoofer with your system requirement. Phase Switch: The Phase switch should be initially set to 0°. Switching On Plug in the mains plug and switch the power on. -
Page 6: Basic Tuning
USER MANUAL: SLIM BASS 8 OPERATING YOUR SUBWOOFER Basic Tuning Volume Setting: Play a programme with extended bass and set the system volume to a resonal level. Adjust the subwoofer volume control to produce the desired level of bass. The bass should be even and an extension of the main loudspeakers. -
Page 7: Specifications
USER MANUAL: SLIM BASS 8 Specifications General Description Active Dynamic-Drive IB subwoofer system Design philosophy and core technology 1x (8")200mm cone long-throw Transducer complement 200mm long throw bass driver 200mv for maximum output Input sensitivity Amlifier Power Output 200W Peak Power Output... - Page 8 IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK Tel: +44(0)1480 452561 Email: service@wharfedale.co.uk http://www.wharfedale.co.uk IAG reserves the right to alter the design and specifications without notice. All rights reserved IAG Group Ltd. Wharfedale is a member of the International Audio Group. CODE: WH18-MNL006a...
