Placement Guide

●
Use this information as a guide to find out about the screen size when the projector is placed at a
certain location, or to find out the approximate size of a screen that will be required.
●
The projection distance over which focussing is adjustable is 1.2 m (3.9 feet) to 6.6 m (21.7 feet). The
projector should be placed within this range.

Screen Size and Projection Distance

8 0 "
6 0 "
4 0 "
3 6 "
Lens surface of
the main unit
1 8 0
"
1 5 0
"
1 2 0
"
1 0 0
"
Screen Size Designation (Inches)
2 0 0
"
E-16
Height from center of
lens to top edge of the
projection
h 1
Height from center
of lens to bottom
edge of the projec-
tion
h 2
Unit: m (feet)
