DATA PROJECTOR
U7 - 132/U7 - 137
User's Manual
* DLP™ (Digital Light Processing) and DMD (Digital Micromirror Device) are registered trademarks of Texas Instru-
ments Incorporated (U.S.A.).
* PC/AT, VGA and XGA are trademarks or registered trademarks of International Business Machines Corporation (U.S.A.).
* S-VGA is a registered trademark of Video Electronics Standards Association.
* Microsoft, Windows, and PowerPoint are registered trademarks of Microsoft Corporation (U.S.A. and other countries).
* Macintosh is a trademark of Apple Computer Inc. (U.S.A.).
* TMDS is a trademark of Silicon Image, Inc.
Note that even in the absence of explanatory notes, serious attention is paid to the trademarks of the various companies
and to the product trademarks.
www.touchboards.com 205 Westwood Ave.Long Branch, NJ 077401-866-942-6273 Sales@touchboards.com
IMPORTANT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U7-132 and is the answer not in the manual?

Questions and answers

Related Manuals for PLUS Vision U7-132

Summary of Contents for PLUS Vision U7-132

  • Page 1 DATA PROJECTOR U7 - 132/U7 - 137 User’s Manual * DLP™ (Digital Light Processing) and DMD (Digital Micromirror Device) are registered trademarks of Texas Instru- ments Incorporated (U.S.A.). * PC/AT, VGA and XGA are trademarks or registered trademarks of International Business Machines Corporation (U.S.A.).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION Precautions Please read this manual carefully before using your PLUS Data Projector and keep the manual handy for future reference. These operating instructions apply to both models U7-132 and U7-137. The two models have the same display resolution and projection distance, but their CompactFlash (CF) card, wireless LAN card and wired LAN functions differ.

  • Page 3: Important Safeguards

    IMPORTANT SAFETY INFORMATION Important Safeguards These safety instructions are to ensure the long life of the unit and to prevent fire and shock. Please read them carefully and heed all warnings. Installation • For best results, use the unit in a darkened room. •...

  • Page 4: Major Features

    Lamp replaceable without removing projector from ceiling The lamp can be replaced from the top of the projector without removing the projector when it is mounted on the ceiling. This eliminates the need to take the projector down to replace the lamp, then to remount the projector and make the projection position adjustments, etc., as required with other projectors.

  • Page 5: Table Of Contents

    Using the Laser Pointer ... E-31 Performing Mouse Operations on the Computer with the Remote Control Unit ... E-32 Controlling the Projector from a Computer ... E-33 Protecting the Projector with the Security Lock ... E-34 Using the Quick Menu ... E-36...

  • Page 6: Table Of Contents

    Table of Contents Menu Operations Menu Operation Method ... E-37 Names and Functions of Buttons Used for Menu Operations ... E-37 Menu Screen Names and Functions ... E-38 Performing Menu Operations ... E-39 Selecting Another Menu Name with Remote Control Operation ... E-41 List of Item Names Offering Input Selection and Adjustments/Settings ...

  • Page 7: Checking The Supplied Accessories

    Remove the main unit and the accessories from the box and check that the following items are included. Wireless remote control unit with laser pointer [1] / Size AAA batteries [2] This controls the projector. (See Page E-11.) DVI/Mini D-Sub 15-pin conversion adapter (18 cm / 0.59 feet) [1] This is used when the monitor connector of the personal com- puter is a mini D-sub 15-pin connector.

  • Page 8: Checking The Supplied Accessories

    When suspending from the ceiling, to prevent the terminal cover from falling, fasten the terminal cover to the projector using the included terminal cover cord as shown on the diagram. “WARNING”...

  • Page 9: Names Of The Main Unit Parts

    Names of the Main Unit Parts Terminal cover Ventilation slots Front adjuster button [E-26] (There is also one on the right side.) Ventilation slots Front adjusters [E-26] Built-in Security Slot This security slot supports the MicroSaver Security System manufactured by Kensington Microware Inc.
  • Page 10 Names of the Main Unit Parts STATUS indicator [E-22, 58] Buttons used in menu and quick menu operations SOURCE button [E-27] MENU button [E-37] Ventilation slots MOUSE connector [E-32] PC CONTROL connector (DIN 9-pin) [E-33] RGB OUT RGB IN RGB IN connector [E-15, 16] RGB OUT connector [E-21] STATUS [E-36, 37]...

  • Page 11: Names Of The Remote Control Parts

    Names of the Remote Control Parts Names of Parts the Remote Control Unit Included with the U7-132 and U7-137 Infrared transmitter [E-12] STANDBY button [E-22, 24] This button is used to switch ON the power aand set the unit to the STANDBY mode.

  • Page 12: Preparing The Remote Control

    Preparing the Remote Control Inserting the Batteries When using the remote control for the first time, install the batteries that were supplied. Slide the battery compartment cover (located on the bottom of the remote control) and pull off. CAUTION When replacing batteries, purchase two of the same type of AAA battery. Heed the regulations in effect in your region on the disposal of spent batteries.

  • Page 13: The Procedure Up To Projecting To The Screen

    When making connections with the video equipment’s YCbCr connector or YPbPr connector, see “Connections with Component Signals” on Page E-19. When playing the audio through the built-in speaker of the projector, see “Connections with Audio Connectors” on Page E-20. Monitoring the analog RGB input signal, see “Connections with the RGB OUT Connector” on Page E-21.

  • Page 14: Placement Guide

    Placement Guide • Use this information as a guide to find out about the screen size when the projector is placed at a certain location, or to find out the approximate size of a screen that will be required. • The projection distance over which focussing is adjustable is 1.20 m (3.9 feet) to 13.81 m (45.31 feet). The projector should be placed within this range.

  • Page 15: Connecting Personal Computers And Video Equipment

    • The projector has been set to “Auto” at the factory; however, if it does not project, please change the input setting to “Digital” using the menu sequence of [Setup] → [Input Format] → [DVI].

  • Page 16: Personal Computers With A Mini D-Sub 15-Pin Connector

    Please orient the connector to mate properly when before inserting it, then turn the screw knobs to secure the connector to that of the projector. The projector has been set to "Auto" at the factory; however, if it does not project, please change the input setting to "RGB" using the menu sequence of [Setup] → [Input Format] → [RGB].

  • Page 17: To Output The External Output Signal Of A Notebook Computer

    Note When the liquid crystal display of the notebook computer and the projector are displayed at the same time, the projected image might not be correct even though the liquid crystal display shows a correct indication. Should this occur, stop the simultaneous display of the notebook computer and try the mode with external output only.

  • Page 18: Connections With Composite Signals

    • Make the connection to the VIDEO connector of the projector using the supplied Video cable. • The input setting of the VIDEO connector has been set to “Auto” at the factory; however, if the projector does not project, please change the input setting to “Your Country’s Television Broadcast System”...

  • Page 19: Connections With Component Signals

    • When connecting the computer to the projector’s RGB connector, connect using a separately sold component cable. • The projector has been set to "Auto" at the factory; however, if it does not project, please change the input setting to "Compo- nent"...

  • Page 20: Connections With Audio Connectors

    Connections with Audio Connectors * Make the connection to the projector’s AUDIO connector using the supplied audio cable. When the audio jack of the equipment that is to be connected is of the RCA phono type, make connection via the supplied audio conversion adapter.

  • Page 21: Connections With The Rgb Out Connector

    • If an input other than DVI or RGB is selected with the input selection function, the output does not switch. • While controlling the personal computer in front of you, the same screen can be projected with the projector. This allows personal computer control even from a position at which the projector image cannot be viewed.

  • Page 22: Power Cable Connections And Switching The Power On/Off

    Switch on the power of the connected equipment Note: • When the power plug will be unplugged from the power outlet, please place the projector near the power outlet so that it may be reached easily. • Press the STANDBY button after the STANDBY indicator is lit in amber.
  • Page 23 The first time the power is switched on after purchase, [Menu Lan- guage Select] will be displayed. Follow the procedure described be- low and select the display language of the projector. If the image is blurred, turn the focus ring counterclockwise or clock- wise to focus it.

  • Page 24: Finishing

    (button on main unit) The [Power Off] display appears. When the level gauge reaches maximum, the projection screen will go off (in about 5 seconds) and the projector will enter the power-off operation. Note * The operation can be cancelled by pressing a button other than the STANDBY button.

  • Page 25: Adjustment Of The Projection Screen

    Adjustment of the Projection Screen Turn the zoom ring to adjust the screen size of the projection image. Adjust the image to match the desired screen size. When outside of the adjustment range, move the projector to the rear or forward.

  • Page 26: Making Adjustments With The Adjusters

    Make adjustments so that there is no rattling. Note: When the projector has a suspended or rear installation is used, the orientation of the projection will need to be changed. Please see “Vertical Flip/Horizontal Flip” on Page E-50. Focus ring...

  • Page 27: General Operation

    Video → S-Video Note * When you do not operate source selection, the projector will assume the input selec- tion condition that was previously used. * See "Auto Source" on Page E-51 for information about the Auto Source on and off conditions.

  • Page 28: Freezing A Moving Picture

    General Operation Freezing a Moving Picture This function is used to stop and view a moving picture. Note that the input image continues to advance even though the picture there is a still picture condition. A press of the FREEZE button changes the screen to a still picture. A further press returns the screen to a moving picture.

  • Page 29: Enlargement Of The Image And Video Movement

    • When “Aspect” is set to “Real” by the signal of the Analog RGB or DVI analog, and the input resolution is higher than the display resolution of the projector. • When “Aspect” is set to “Zoom” by the video signal.

  • Page 30: Using The Presentation Timer

    Note: * The timer display is not displayed when a menu or message is displayed or when the “Wireless Projector” setting screen is being projected, but the timer continues functioning. The timer display is also not displayed when no signals are being input.

  • Page 31: Using The Laser Pointer

    General Operation Using the Laser Pointer The remote control unit’s laser pointer can be used to point to the section currently being explained, making presenta- tions more effective. CAUTION Do not look at the laser pointer’s light source. Be sure to heed the following. Pointing the laser beam at the eyes could lead to reduced vision or vision impairment.

  • Page 32: Performing Mouse Operations On The Computer With The Remote Control Unit

    5 seconds before reconnecting. Do not repeatedly disconnect and reconnect the cable in a momentary fashion. The personal computer may not be able to correctly identify the projector as a result. * The supplied USB cable is a dedicated cable for this projector. There is no guaranty that it will work in connections with other USB equipment.

  • Page 33: Controlling The Projector From A Computer

    Note: * This function may not work with some computers. * Specialized knowledge is required to use the control connector. Consult a specialist, such as the person suspending the projector from the ceiling. * Have the order-made cable made by a specialist with the required specialized knowledge based on the pin assignment shown above.

  • Page 34: Protecting The Projector With The Security Lock

    General Operation Protecting the Projector with the Security Lock A password can be registered and the security lock set in order to protect the projector from unauthorized use. Registering the password The password is registered using the menus. For instructions on operating the menus, see “Menu Operation Method” on E-37.
  • Page 35 When a password has been registered, the “Password” input window appears on the projected image when the power is turned on. The projector continues projecting this image until the correct password is input. At this time, only the STANDBY button (power off) works.

  • Page 36: Using The Quick Menu

    General Operation Using the Quick Menu This function permits frequently used adjustments to be performed quickly. Note that the Quick Menu will not be displayed unless the signal of the con- nected equipment is input. Please select the input that you wish to adjust. Main unit operation (1) Press the QUICK MENU button to display the quick adjustment display.

  • Page 37: Menu Operation Method

    • Adjustments and settings are made by projecting an image and adjusting to an optimum condition. • The remote control should be pointed toward the remote control sensor of the projector and operated. • To return the various items that have been changed via the menu to their standard values (i.e., default values at time of shipping from the factory), see “Factory Default”...

  • Page 38: Menu Screen Names And Functions

    Menu Operation Method Menu Screen Names and Functions Menu Name This is the title of the menu. There is a change to the title screen when the menu is selected. The cursor moves to the selected menu name. Item Name This is the name of the ad- justment or setting.

  • Page 39: Performing Menu Operations

    Preparation Switch on the power of the connected equipment, start the play operation or another operation, and input the signal to the projector. Select the input that you wish to adjust. The menu display of the description diagram depicts an example in which the “Keystone” item name is selected.
  • Page 40 Menu Operation Method Displaying the Cursor Press the SELECT button to display the item name selection cursor. STANDBY LASER VIDEO AUTO MENU QUICK R-CLICK/ ENTER CANCEL TIMER FREEZE MUTE Selection of the Item Name Press the SELECT ( STANDBY LASER VIDEO AUTO MENU...

  • Page 41: Selecting Another Menu Name With Remote Control Operation

    Menu Operation Method Closing the Menu Press the MENU button and close the menu display STANDBY LASER VIDEO AUTO QUICK MENU R-CLICK/ ENTER CANCEL FREEZE MUTE TIMER Selecting Another Menu Name with Remote Control Operation When a sub menu is displayed, press the CANCEL but- ton and close the sub menu.

  • Page 42: List Of Item Names Offering Input Selection And Adjustments/Settings

    Menu Operation Method List of Item Names Offering Input Selection and Adjustments/Settings The item names that can be adjusted/set will differ depending on the input signal. [Example of Menu Display Items at the Time of Input Signal RGB Selection] Menu name Item Name Image Brightness...
  • Page 43 Menu Operation Method Menu name Item Name Setup Auto Source Auto Power Off Menu Position Lamp Mode Input Format Presentation Timer Option Language On Screen Background Startup Screen Security Lock Network Password Info. Status Factory Default Lamp Timer Reset Resolution Frequency Lamp Timer Imput...

  • Page 44: Image

    Image • Perform this operation while projecting the picture for which the adjustment/setting will be made. • Select the menu name “Image”. See “Menu Operation Method” on Page E-37 for information about performing menu operations. The item name display will differ depending on the input signal.

  • Page 45: Fine Picture

    Image Fine Picture Adjust this when the picture shows a lack of color fidelity or flickering. Select the “Fine Picture” item name and adjust with the SELECT ( tons so that the lack of color fidelity or the flickering disappears. H Position Adjust this when the picture is shifted to the left or right.

  • Page 46: Color

    Color • Do the following operation while displaying the image you want to adjust or set. • Select the menu name “Color”. See “Menu Operation Method” on Page E-37 for information about performing menu operations. The item name display will differ depending on the input signal.

  • Page 47: Color Temp

    Note: * When the component signal undergoes conversion processing to red, green, and blue which express the image of the projector, the correct color cannot be reproduced unless a system compliant with the color difference conversion sys- tem of the input signal is used. Color Space serves to make this selection.

  • Page 48: White Balance

    Color White Balance The black and white levels of the analog RGB or DVI analog input sig- nals being projected are adjusted automatically for the computer. This increases color reproducibility. Select the item name [White Balance] and press the ENTER button. The display will change to [Input Black Signal].

  • Page 49: View

    Note: • When selection has been made for the “Real” setting of the personal computer signal (i.e., when the input signal and the projector display resolution are high) and the “Zoom” setting of the video signal, pressing the SELECT ( movement of the display position.

  • Page 50: Vertical Flip / Horizontal Flip

    Vertical Flip / Horizontal Flip This is the selection of how images are projected on the screen. Set this when the projector is suspended from the ceiling, installed on its back, etc. Select the item name “Vertical Flip” or “Horizontal Flip” and select the setting contents with the SELECT ( ) buttons.

  • Page 51: Setup

    Note: Some video decks and other equipment output a blue background or other video when playback ends. When this happens, a signal is being input to the projector and Auto Power Off is not activated. Menu Position This function sets the display position of the menu.

  • Page 52: Lamp Mode

    Setup Lamp Mode Use this if the picture is projected on a small screen and the picture is too bright or when projecting images in dark rooms. Select the item name “Lamp Mode” and select the setting contents with the SELECT ( ) buttons.

  • Page 53: Presentation Timer

    Setup Presentation Timer The presentation is given while checking the timer displayed on the screen. The gauge display allows the remaining time to be known at a glance. Select the item name “Presentation Timer” and select the setting contents with the SELECT ( ) buttons.

  • Page 54: Language

    Option • Select menu name “Option”. See “Menu Operation Method” on Page E-32 for information about performing menu operations. The item name display will differ depending on the input signal. See “List of Item Names Offering Input Selection and Adjustments/Settings” on Page E-42. Language This function sets the language that is displayed on screen in the messages and menu displays.

  • Page 55: Startup Screen

    Enable ... The security lock is enabled. The security lock is activated when the power is turned on, and the password must be input in order to operate the projector. Network Password For details, refer to the “Image Viewer / Network” manual.

  • Page 56: Info

    There is a change to the status display. Press the CANCEL button to return to the menu. Display Contents: Projector model, firmware version, and the internet home page ad- dress of PLUS Vision Corp. Factory Default This function returns the adjustments and settings of all the in- put sources to the standard factory default values.

  • Page 57: Resolution / Frequency

    This function displays the resolution and frequency of the detected in- put signal. Lamp Timer This displays the lamp timer. This projector has an Eco mode function. The lamp life will differ between Normal mode and Eco mode. Lamp Life Use only in Normal mode: approx.2000 hours Use only in Eco mode: approx.3000 hours...

  • Page 58: When An Indicator Is Lit Or Blinking

    2. Check the following matters and take the required measures. When the projector is being used in a location that has a high ambient temperature, set it up again in a cool location. Check the outflow and intake holes and clean them if they are obstructed.

  • Page 59: Troubleshooting

    • Does the projection distance exceed the focusing range? • Is there condensation on the lens, etc.? If the projector is moved from a cool storage area to a warm place and the power is turned on, condensation may form on the lens or internal optical parts.

  • Page 60: Cleaning

    Cleaning the Inside of the Projector Cleaning of the inside of the projector is required about once a year. Failure to clean over a long period while dust has collected inside the projector could cause a fire or breakdown. Do not clean the inside of the projector by yourself. Please be sure to contact your dealer.

  • Page 61: Replacing The Lamp Cartridge

    Replacing the Lamp Cartridge • The lamp that is used as a light source in the projector has a limited service life. The rated service life of the lamp is about 2000 hours (when used in normal mode only). This could be shortened depending on conditions of use and other factors.
  • Page 62 Replacing the Lamp Cartridge Unplug the power cord. Turn the projector upside-down. Remove the lamp cover. (1) Turn the lamp cover’s set screw counterclockwise and loosen until the screw turns freely. (The screw does not come off.) Remove the lamp cartridge.
  • Page 63 5 seconds will clear the lamp timer. Checking that the STATUS indicator is out will show that the lamp timer has been cleared. Contact a store that sells the U7-132/U7-137 for a replacement lamp. Indicate you need a U7-300 replacement lamp for the U7-132/U7-137 (order code 28-057).

  • Page 64: Specifications

    3.0 kg / 6.6 lbs U7-137 : 3.1 kg / 6.8 lbs Operational Temperatures Data projector: 5° to 35°C (41° to 95°F), 30 to 85% humidity • Specifications and design are subject to change without notice. 1024 768 dots E-64...

  • Page 65: Table Of Supported Frequencies

    Table of Supported Frequencies The projector automatically identifies the signal input from the computer and selects the optimum resolution as shown on the table below. Manual adjustments may be required for some input signals. See “Picture Adj. / Fine Picture / H Position / V Position” on page E- 44, 45.

  • Page 66: Cabinet Dimensions

    Cabinet Dimensions OPEN OPEN PRESS PRESS MENU MENU QUICK AUTO SOURCE STANDBY STATUS 258 (10.2) Unit: mm (inch) E-66...
  • Page 67 2005...

This manual is also suitable for:
