PC Control Specification Release N
Revision History
Release C
Applied firmware release
Release E
Reply format corrected for ES, ET, LT, RT, UP, DN commands
Release F
Reply format corrected for QE, SS commands
Release G
Release H
Release J
Release K
Release L
Release M
Release N
Model query command added
Othello function control command added
Commands with argument added
A command which saves current while balance, R, G and B
contrast and brightness, into nonvolatile memory added.
Source Select command added
Source Query command reply modified
Applied to U2 model
Commands added : SOURCE, RGB, VIDEO button functionality
#Qu command added
#CE command added
Supported 9600 bps control
telnet protocol supported
reply timeout documented
14/26
Ref. Firmware 05/01/17A (x.22.3.83) or later
PLUS Vision Corp.
2005/1/17
Advertisement
Related Manuals for PLUS Vision RS-232
Summary of Contents for PLUS Vision RS-232
-
Page 1: Revision History
Commands added : SOURCE, RGB, VIDEO button functionality Release L #Qu command added Release M #CE command added Supported 9600 bps control Release N telnet protocol supported reply timeout documented Ref. Firmware 05/01/17A (x.22.3.83) or later 14/26 PLUS Vision Corp. 2005/1/17... - Page 2 U4/U7/U8 series projectors which has wired/wireless LAN functionality. Notice Projector’s behavior may be changed on changing firmware without notice. This specification may be changed without notice. A projector which working with an earlier firmware can be driven by updating its firmware. Contact http://www.plus-vision.com Ref.
- Page 3 RS-232C connection DIN Sub 9 pin (male) Pin 2 Transmit Data Pin 3 Receive Data Pin 5 Signal Ground telnet connection Projector should be connected via wired or wireless LAN. 2. Electrical RS-232C connection TIA/EIA-232 compliant 3. Protocol RS-232C connection Baud Rate 115.2Kbps (Default) ,19.2Kbps or 9600bps...
- Page 4 Return (Projector to Host) #RT_[CR][LF] 1) Command with Arguments Prefix Command/Return Suffix Prefix > (3Eh) Suffix CR (0Dh) LF(0Ah) Ex) command (Host to Projector) #BB255[CR][LF] Return (Projector to Host) #BB169_[CR][LF] Ref. Firmware 05/01/17A (x.22.3.83) or later 17/26 PLUS Vision Corp. 2005/1/17...
- Page 5 Issuing next commands without waiting response will cause system problems. Case Command Packet Command Packet Ref. Firmware 05/01/17A (x.22.3.83) or later Host Direction (Normally within 0.5Sec it returns packet. executing source status) 18/26 PLUS Vision Corp. 2005/1/17 Projector (Process) Return Packet Depends on command (Process) Return Packet...
- Page 6 Same as VIDEO button on remote Ref. Firmware 05/01/17A (x.22.3.83) or later Return Description Fail Pass Fail Pass Fail Pass input from Fail Pass input from Fail Pass Fail Pass Fail Pass Fail Pass Pass Pass Pass 19/26 PLUS Vision Corp. 2005/1/17...
- Page 7 Fail Onscreen disabled Onscreen enabled Fail Unfreezed Freezed Fail Auto Direct Real Wide Zoom Fail Normal Mode Eco Mode Fail Pass Fail Not flipped flipped Fail Not flipped flipped Fail Normal Natural Real Fail Pass 20/26 PLUS Vision Corp. 2005/1/17...
- Page 8 DN_ or DN1 Pass Fail LT_ or LT1 Pass Fail RT_ or RT1 Pass Fail ET_ or ET1 Pass Fail ES_ or ES1 Pass hh:Value in hexadecimal format. ex V2A Operation failed if hh is 80. 21/26 PLUS Vision Corp. 2005/1/17...
- Page 9 Lamp cover opened Too hot Fan error Lamp ignition error Lamp life expired Lamp should be changed. Lamp ignition error Lamp error Version in hexadecimal format QVhh.hh.hh.hh Ex) “QV01.07.02.0d” QUhhhh Hhhh hours in hexadecimal format 22/26 PLUS Vision Corp. 2005/1/17...
- Page 10 : same value in returned packed of QS command e : same value in returned packed of QE command r : same value in returned packed of QR command p : same value in returned packed of QP command 23/26 PLUS Vision Corp. 2005/1/17 from...
- Page 11 Fail Pass Fail model * model dmd option * dmd * option Between and (option), there will be one or more space (0x20) characters. 24/26 PLUS Vision Corp. 2005/1/17 U5 series SVGA No option Othello available BB , (model), (dmd)
- Page 12 In case the projector’s current baud rate is unknown, send (Don’t expect) these (Don’t expect) 115.2Kbps and 19.2Kbps. * Even in telnet connection, this command communication speed. White Pass This 25/26 PLUS Vision Corp. 2005/1/17 command telnet command using both changes RS-232C...
- Page 13 050 <= nnn <= 149 (Decimal) disable keystone adjustment Values other than above will be taken as a value query. 26/26 PLUS Vision Corp. 2005/1/17 Projector to PC (return) Description CRnnn0 Fail CRnnn_ Pass CGnnn0...
