Names of the Main Unit Parts

STATUS indicator [E-61]
POWER button [E-24]
SOURCE button [E-28]
Exhaust vents
Front adjuster
Remote control sensor
Lens
Precautions
The ventilation slots discharge the heat of the lamp and care must be taken not to come into
contact with them.
A U
D I O
V I D
E O
Speaker
Focus ring [E-27]
E-10
POWER indicator [E-24]
MENU button [E-38]
AUTO button [E-28]
QUICK MENU button [E-32]
Remote control
sensor [E-14]
Front adjuster button [E-27]
(There is also one on the left side.)
Lens cap
To protect the lens, attach the lens
cap when the projector is not in use.
Exhaust
vents
Ventilation
slots
