NAMES OF PARTS

MAIN UNIT DISPLAY
Filter replacement lamp
AUTO operation lamp
Remote control receiver
Odor sensor
(Detects odors such as tobacco smoke,
incense, pets, cosmetics, etc.)
EXPLODED
DIAGRAM
It can't remove the noxious substances
*
(carbon monoxide etc.) of cigarette.
Tobacco smoke removal operation lamp
*
Fan level lamps
Silent High
Median Max
Dust sensor
(Detects dust, smoke, pol-
len, house dust, etc.)
Pollen removal operation lamp
OFF timer display lamps
(set using remote control)
Clean-sign lamp
The color changes when the air is dirty
Clean (green) Little dirty (orange) Very dirty (red)
E-4
Power lamp
(Lights when the power plug is
inserted into the wall outlet)
Plasmacluster
Operation select/OFF button
(Used to select operations or turn
the unit off)
Main unit
HEPA filter (white)
(Dust collection filter)
(W/ apatite antibacterial filter)
Stamina-power carbon (black)
(Deodorization filter)
Pre-filter
Front panel
Remote control
Hook
Stand
(Be sure to mount for tabletop instal-
lation)
Thumbscrew
