Zotac IONITX-U series User Manual page 8

Figure 2
2
1. PS/2 Keyboard Port
3. HDMI Port (Optional)
5. DVI Port
7. Port
Blue
Green
Pink
8. LAN port LED indicators
Speed LED Activity LED
9. 19V DC Power input (Optional)
This motherboard contains a DC power input jack (as picture 1). Users can plug a 19V AC/
DC adapter to the DC power input jack (as picture 2). Please use a 19V DC power adapter
instead of ATX power supply. Picture 3 is the final image.
1
3 4
2-Channel
Line-In
Line-Out
Mic In
Speed LED
Status
Off
Green
Orange
5
2. USB 2.0 Ports
4. SPDIF Ports
6. USB 3.0 Ports
4-Channel
Rear Speaker Out
Front Speaker Out
Mic In
Description
Speed: 10 Mbps
Speed: 100 Mbps
Speed: 1000 Mbps
2
3
8
2 7 9
6
6-Channel
Rear Speaker Out
Front Speaker Out
Center/Subwoofer
Activity LED
Status
Off
Orange
Blinking
Rear panel
10
Descritption
No link
Linked
Data activity
7
