- Page 2 Electronic Emission Notices WARNING! Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 3: Table Of Contents
Intel D2500-MATX series Motherboard Table of Contents Motherboard Specifications ---------------------------------------------------------------------------------4 Motherboard Layout--------------------------------------------------------------------------------------------6 Hardware Installation ------------------------------------------------------------------------------------------8 Safety Instructions-------------------------------------------------------------------------------------------8 Installing Memory Modules--------------------------------------------------------------------------------9 Installing the Motherboard --------------------------------------------------------------------------------10 Installing the I/O Shield -------------------------------------------------------------------------------10 Securing the Motherboard into the Chassis -----------------------------------------------------10 Connecting Cables and Setting Switches -------------------------------------------------------------11 24-pin ATX Power Connector-PW1 ----------------------------------------------------------------12 4-pin ATX_12V power connector-PW2 -----------------------------------------------------------12 COM Header-COM1 (Optional)---------------------------------------------------------------------13... - Page 4 Table of Contents Save as User Defaults --------------------------------------------------------------------------------25 Restore User Defaults --------------------------------------------------------------------------------25 Launch EFI Shell from filesystem device --------------------------------------------------------25 Flash Update Procedure ----------------------------------------------------------------------------------26 Installing Drivers and Software ----------------------------------------------------------------------------27 Drivers Installation ------------------------------------------------------------------------------------------27 Realtek HD Audio Driver Setup -------------------------------------------------------------------------28 Getting Started ------------------------------------------------------------------------------------------28 Digital Output --------------------------------------------------------------------------------------------28 Speakers --------------------------------------------------------------------------------------------------30 Microphone -----------------------------------------------------------------------------------------------31...
-
Page 5: Motherboard Specifications
Intel D2500-MATX series Motherboard Motherboard Specifications q Chipset v Intel ® NM10 Chipset q Size v MATX form factor of 9.25 inch X 6.69 inch q Microprocessor support v Intel ® CedarView D2500 q Operating systems v Supports Windows 7 32bit q System Memory v Supports 1 GB, 2 GB and 4 GB DDR3 SO-DIMM devices v Supports DDR3 SO-DIMM 1066 MT/s... - Page 6 Motherboard Specifications q Onboard Graphics Features v Intel ® Media Accelerator 3600 series Graphics v VGA and HDMI ports output support q PCI Express Interface v Supports PCI Express 2.0 v Wake up function is supported v Clock spread spectrum capability q Expansion slots v One PCI Express x16 slot (single lane) v One Mini PCI Express slot for full sized and half sized Mini PCIe card...
-
Page 7: Motherboard Layout
Intel D2500-MATX series Motherboard Motherboard Layout Figure 1 shows the motherboard and Figure 2 shows the back panel connectors. DDRIII2 DDRIII1 Chipset SPDIF F_AUDIO PCIE1 PCIE2 SATA2 SATA1 PCI1 FP_U1 PCI2 COM1 FP_U2 SPK1 Figure 1 Figure 1. Board Layout 1. - Page 8 Rear panel Figure 2. Backpanel connectors 1. PS2 Mouse Port 2. PS2 Keyboard Port 3. HDMI Port 4. VGA Port 5. USB 2.0 Ports 6. Port 2-Channel 4-Channel 6-Channel Blue Line-In Rear Speaker Out Rear Speaker Out Green Line-Out Front Speaker Out Front Speaker Out Pink Mic In...
-
Page 9: Hardware Installation
Intel D2500-MATX series Motherboard Hardware Installation This section will guide you through the installation of the motherboard. The topics covered in this section are: q Installing Memory Modules q Installing the Motherboard q Connecting Cables and Setting Switches Safety Instructions To reduce the risk of fire, electric shock, and injury, always follow basic safety precautions. -
Page 10: Installing Memory Modules
Hardware Installation Installing Memory Modules Your new motherboard has two 1.5V 204-pin slots for DDR3 SO-DIMM memory. These slots support 1 GB/2 GB/4 GB DDR3 SO-DIMM devices. There must be at least one memory bank populated to ensure normal operation. DDRIII2 DDRIII1 Refer to the following procedure to install memory modules into the slots on the motherboard. -
Page 11: Installing The Motherboard
Intel D2500-MATX series Motherboard Installing the Motherboard The sequence of installing the motherboard into the chassis depends on the chassis you are using and if you are replacing an existing motherboard or working with an empty chassis. Deter- mine if it would be easier to make all the connections prior to this step or to secure the mother- board and then make all the connections. -
Page 12: Connecting Cables And Setting Switches
Connecting Cables and Setting Switches This section takes you through all the connectors and switch settings necessary on the mother- board. This will include: q Power Connectors v 24-pin ATX Power Connector-PW1 v 4-pin ATX_12V Power Connector-PW2 q Internal Headers/Connectors v COM Header-COM1 (Optional) v Front Panel Header-FP1 v USB Headers (FP_U1/2) -
Page 13: 24-Pin Atx Power Connector-Pw1
Intel D2500-MATX series Motherboard 24-pin ATX Power Connector-PW1 PW1 is the main power supply connector. Make sure that the power supply cable and pins are properly aligned with the connector on the motherboard. Firmly plug the power supply cable into the connector and make sure it is secure. -
Page 14: Com Header-Com1 (Optional)
Hardware Installation COM Header-COM1 (Optional) COM1 - Pin Definition Signal Signal Front Panel Header-FP1 The front panel header on this motherboard is one connector used to connect the following four cables : COM1 FP1-Pin Definition Signal Signal HDD_LED+ PW_LED+ HDD_LED- PW_LED- PWR_SW RESET... -
Page 15: Usb Headers-Fp_U1~Fp_U2
Intel D2500-MATX series Motherboard USB Headers-FP_U1~FP_U2 This motherboard contains four USB 2.0 ports that are exposed on the rear panel of the chassis. The motherboard also contains two 10-pin internal headers connector onboard. Note: Secure the bracket to either the front or rear panel of your chassis (not all chassis are equipped with the front panel option). -
Page 16: Speaker Header-Spk1
Hardware Installation SYSFAN1 +12V Sense Control SATA2 SATA1 Speaker Header-SPK1 SPK1-Pin Definition SPK1 Assignment SPK- Serial-ATA (SATA) Connectors (SATA1/2) SATA-Pin Definition The Serial ATA connector is used to connect the Serial ATA Signal device to the motherboard. These connectors support the thin Serial ATA cables for primary storage devices. -
Page 17: Expansion Slots
Intel D2500-MATX series Motherboard Expansion Slots The motherboard contains five expansion slots, including one PCI Express x16 slot, one mini PCI Express slot, one PCI Express x1 slot and two PCI slots. PCIE1 PCIE2 M_PCIE1 PCI1 PCI2 PCI Express x16 Slot (single lane)-PCIE1 There is one PCI Express x16 slot reserved for graphics or video cards. -
Page 18: Jumper Settings
Hardware Installation Jumper Settings This section explains how to configure the motherboard’s hardware. Before using your computer, make sure all jumpers and DRAM modules are set correctly. Refer to this section whenever in doubt. CMOS Clear Jumper-JP1 Selection 1-2* Normal* CMOS Clear Close Open... -
Page 19: Configuring The Bios
Intel D2500-MATX series Motherboard Configuring the BIOS This section discusses how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. Enter BIOS Setup The BIOS is the communication bridge between hardware and software. Correctly setting the BIOS parameters is critical to maintain optimal system performance. -
Page 20: Advanced Menu
Configuring the BIOS q System Language Choose the system default language. q System Date/Time Allows you to set the system date/time. Advanced Menu The Advanced menu items allow you to change the setting for the CPU and other system devices. Press <enter> to display the configuration options: OnBoard Device Config The items in this menu allow you to set PCI Express port, HD Audio and so on. -
Page 21: Hdd Storage Configuration
Intel D2500-MATX series Motherboard HDD Storage Configuration The items in this menu allow you to set or change the storage configurations. Press <enter> to display the configuration options: q SATA Controller Allows you to configure SATA controller. q Configure SATA as This item allows you to configure SATA as IDE/AHCI mode. -
Page 22: Pc Health Menu
Configuring the BIOS q Device reset time-out Allows you to set device reset time-out. q Device power-up delay Allows you to set device power-up delay. PC Health Menu Select PC Health from the BIOS Setup Utility menu to display the system menu. -
Page 23: Power Management Menu
Intel D2500-MATX series Motherboard Power Management Menu The items in this menu allow you to control the system power management. Press <Enter> to display the configuration options: q Enable Hibernation Enable or disable system ability to hibernation (OS/S4 Sleep State). This option may be not effective with some OS. -
Page 24: Boot Menu
Configuring the BIOS Boot Menu The Boot menu items allow you to change the system boot options. Press <enter> to display the configuration options: q Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. q Bootup NumLock State Use this item to select the keyboard NumLock state: [On] or [Off]. -
Page 25: Save & Exit Menu
Intel D2500-MATX series Motherboard q Full Screen Logo This option allows you to enable or disable the display of the full-screen logo when the system boots. Use the <Page Up> and <Page Down> keys to toggle between [Enable] and [Disable]. q GateA20 Active When set to [Upon Request], GA20 can be disabled using BIOS services. -
Page 26: Discard Changes And Exit
Configuring the BIOS Discard Changes and Exit Select this option only if you do not want to save the changes that you have made to the setup program. If you made changes to fields other than system date, system time, and password, the BIOS asks for a confirmation before exiting. Save Changes and Reset Select this item and press <Enter>... -
Page 27: Flash Update Procedure
Intel D2500-MATX series Motherboard FLASH Update Procedure The program EFUDOS.exe is included in the driver dsk (X:\Utility\EFUDOS.exe). Please follow the recommended procedure to update the flash BIOS, as listed below. (X: your driver disk letter). 1. Create a DOS-bootable floppy diskette. Copy the new BIOS file (just obtained or downloaded) and the utility program EFUDOS.exe to the diskette. -
Page 28: Installing Drivers And Software
Installing Drivers and Software Note: It is important to remember that before installing the driver DVD that is shipped in the kit, you need to load your operating system. The motherboard supports Windows 7 32bit. The kit comes with a DVD that contains utility drivers and additional INTEL software. The DVD that has been shipped with your motherboard contains the following software and drivers: q Intel Chipset Driver... -
Page 29: Realtek Hd Audio Driver Setup
Intel D2500-MATX series Motherboard Realtek HD Audio Driver Setup Getting Started After Realtek HD Audio Driver being installed (insert the driver dsk and follow the on-screen instructions), “Realtek HD Audio Manager” icon will show in System tray as below. Double click the icon and the control panel will appear: Double click to enable Realtek HD Audio Manager... - Page 30 Installing Drivers And Software Environment Simulation You will be able to enjoy different sound experience by pulling down the arrow, totally 23 kinds of sound effect will be shown for selection. Realtek HD Audio Sound Manager also provides five popular settings “Sewer pipe”, “Bathroom”, “Arena”, “Stone Room”, and “Auditorium” for quick enjoyment.
-
Page 31: Speakers
Intel D2500-MATX series Motherboard Speakers Realtek HD Audio Manager frees you from default speaker settings. Speakers includes four tabs: Speaker Configuration, Sound Effects, Room Correction and Default Format. Speaker Configuration In this tab, you can choose speaker configuration: Stereo, Quadraphonic or 5.1 Speaker using “Up/Down Arrow”. -
Page 32: Microphone
Installing Drivers And Software Microphone This page is designed to provide you better microphone/recording quality. Below picture indicates both “Noise Suppression” & “Acoustic Echo Cancellation” are both enabled. Noise Suppression If you feel that the background noise, especially the sound generated from the fan inside PC, is too loud? Try “Noise Suppression”, which allows you to cut off and suppress disturbing noise. -
Page 33: Line
Intel D2500-MATX series Motherboard Line In Realtek HD Audio Manager integrates “Volume Control” functions into the Line In page. This gives you the advantage to you to create your favorite sound effect in one single tool. Single click on the volume icon , the Recording/Playback Volume will be changed to the mute mode.
