Jenn-Air JS42PPDUDB01 Parts List page 26

Illus. Part
No. No. DESCRIPTION
1 304392 Screw 8−18 x 1/2
2 2320601 Shield, Valve
5 628379 Clip, Fuse
6 W10174395 Tube, Filter Inlet
7 2320658 Water Tube
8 2302758 Seal Gasket
9 2317912 Tube, Filter
Outlet
10 W10159842 Valve, Solenoid
12 2221070 Clamp, Tube
13 2320559 Support, Valve
15 2208136 Clamp, Nylon
Valve
17 2302756 Tube, Water Inlet
18 2221232 Cover
20 W10122527 Mold & Heater
(Also Order
542638 Silicone
Grease)
ICEMAKER PARTS
For Model: JS42PPDUDB01
(Stainless Steel)
Illus. Part
No. No. DESCRIPTION
21 Motor, (Not
Serviceable Order
Item 35)
22 628356 Cup−Water Fill
23 627843 Ejector
24 2198598 Ice Striper
25 2194712 Support
26 2315522 Retainer
Thermostat (2)
27 628397 Thermostat
(Also Order
542639 Cement
Alumilastic)
28 8533917 Screw
29 W10139199 Wire Assembly,
Smart Valve
30 489276 Screw
31 W10151255 Cover, Icemaker
26
Illus. Part
No. No. DESCRIPTION
32 W10223929 Module Assembly
(Includes Items
21 & 33)
33 489136 Screw (2)
34 489464 Screw
35 486194 Screw
36 2252228 Bracket, Icemaker
Mounting
100 W10190968 Complete Icemaker
Assembly
Following Parts Not Illustrated
(Optional Parts Only)
8537055 Cleaner,
Stainless Steel
W10151245 Ice Container
Assembly
W10231838
