Shop fox M1016 Specifications

Product Dimensions

Weight.......................................................................................................... 353 lbs.
Width (side-to-side) x Depth (front-to-back) x Height................................... 44 x 23 x 17-1/2 in.
Footprint (Length x Width)......................................................................... 16-1/2 x 43 in.

Shipping Dimensions

Type....................................................................................................... Wood Crate
Content........................................................................................................ Machine
Weight.......................................................................................................... 386 lbs.
Length x Width x Height........................................................................... 47 x 26 x 23 in.

Electrical

Power Requirement.................................................................... 110V, Single-Phase, 60 Hz
Prewired Voltage................................................................................................. 110V
Full-Load Current Rating........................................................................................... 8A
Minimum Circuit Size............................................................................................. 15A
Connection Type......................................................................................... Cord & Plug
Power Cord Included.............................................................................................. Yes
Plug Included....................................................................................................... Yes
Included Plug Type............................................................................................... 5-15
Switch Type................................................................. Forward/Reverse & Button Switches

Motors

Main
Type......................................................................... TEFC Capacitor-Start Induction
Horsepower.............................................................................................. 3/4 HP
Phase.............................................................................................. Single-Phase
Amps........................................................................................................... 8A
Speed.................................................................................................. 1725 RPM
Bearings................................................................. Sealed & Permanently Lubricated

Main Specifications

Operation Info

Swing Over Bed........................................................................................ 9.75 in.
Distance Between Centers.............................................................................. 21 in.
Swing Over Cross Slide.................................................................................... 6 in.
Swing Over Saddle......................................................................................... 6 in.
Maximum Tool Bit Size................................................................................. 1/2 in.
Compound Travel..................................................................................... 2-1/4 in.
Carriage Travel........................................................................................... 20 in.
Cross Slide Travel.................................................................................... 4-1/4 in.
MODEL M1016
SHOP FOX 10" X 20" METAL LATHE
®
Model M1016 Machine Specifications, Page 1 of 3
