Wind Crest WER Series Install Quick Specs

Installation Type & Discharge Direction
Wall – vertical discharge
Discharge Size off Hood Top
14" x 4 1/4" rectangular
Discharge Transition – purchased
separately
See "Ventilation" section for options

Standard Features

•
304 Series, 18 gauge stainless steel
•
Halogen lighting (dual 50 watt lamps 36" to
48" widths/four 50 watt lamps 60" width –
with Hi/Lo setting
•
Dishwasher safe, heavy aluminum mesh
filters
•
All Stainless Steel Finish Hoods can be
installed Indoors or Outdoors (see
Installation Instructions)
•
Widths: 36", 42", 48" and 60"

Finishes

•
Stainless Steel (S), White (W), Essence of
Copper (E) and Pewter (P)

Optional Upgrades

•
250 Watt Heat Lamp Fixtures (add "H" to
hood model number) e.g. WER364SH
•
6" or 12" Canopy Extensions in matching
finish (Model(s): 6EC36S or 12EC36S for
36" wide hood in stainless steel finish).
NOTE: Specify desired canopy height,
width and finish when ordering.
•
Chrome or Brass Rolled Pot Rails
(Model(s): ACCBRC or ACCBRB) – indoor
use only
•
Stainless Steel Back Splash with drop-
down chrome racks supports a maximum
of 30 lbs. (BS plus width – e.g. BS36)
Copyright 2006 Wind Crest by CNP Industries
Install Quick Specs are for planning purposes only. Please refer to the detailed installation instructions, prior to
.
making any cutouts
Wall Mounted Hoods – Install Quick Specs
WER Series Hoods - 24" Depth
Hood Carton Weight:
WER364 = 58 lbs.
WER424 = 65 lbs.
Wiring Access
3"
WER Hoods
"BS" Warming Shelf
Accessory with Chrome Racks
WER484 = 72 lbs.
WER604 = 85 lbs.
C L
U L
LISTED 7Z66 C
1
18"
U L
13"
