Summary of Contents for Wind Crest WCG300S
- Page 1 WCG300S WCG360S Model number: Serial Number: Date of Purchase: Sales Dealer: MAR12.0501 Copyright © 2011 CNP Industries, Inc. READ AND SAVE THESE INSTRUCTIONS...
- Page 2 www.windcrestcnp.com...
- Page 3 SAFETY NOTICE ..............LIST OF MATERIALS ............INSTALLATION Ducting Calculation Sheet ........Mounting Height & Clearance ........ Ducting Options ............Hood Specifi cations ........... Mounting the Hood ............ FEATURES & CONTROLS Touch Controls ............. Charcoal Filter Change Reminder ....... Mesh Filter Clean Reminder ........
- Page 4 www.windcrestcnp.com READ AND SAVE THESE INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE CONTROL DEVICE. WARNING TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: a.
-
Page 5: Operation
15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to Electrical Diagram on product. A cable locking connector (not supplied) might also be required by local codes. Check with local requirements, purchase and install appropriate connector if necessary. WCG300S & WCG360S - MAX 400 Watts, 3.2 Amps... -
Page 6: Hardware Package Contents
MODELS: WCG300S & WCG360S PARTS SUPPLIED 1 - Hood with internal blower 1 - Duct cover wall bracket 1 - Duct cover assembly (top and bottom) 1 - 6” round backdraft damper (pre-installed) 2 - 50W GU-10 halogen light bulbs (pre-installed) - Page 7 Equivalent number Equivalent number Duct pieces Duct pieces length x used T otal length x used T otal 3- 1/ 4” x 10” 1 Ft. 6”- 8” Round 30 Ft. Rect., wall cap straight with damper 7” Round, 1 Ft. 6”- 8”...
-
Page 8: Damage - Shipment/Installation
www.windcrestcnp.com Minimum mount height between range top to hood bottom should be no less than 26”. Maximum mount height should be no higher than Min. ducted 27” 34”. Min. recirc. 31-1/2” Max. 50” It is important to install the hood at the proper mounting height. - Page 9 WARNING FIRE HAZARD NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside, unless using the recirculating option. Ductless or recirculating installations require an accessory kit. Turn to page 17 for part number and ordering information.
- Page 10 www.windcrestcnp.com 10-9/16” 10-3/8” Min. Ducted - 27” Min. Recirc. - 31-1/2” Maximum - 50” 19-11/16” 29-15/16” or 35-7/16” 19-3/4” FRONT SIDE 6-13/16” 8-15/16” BACK...
- Page 11 CAUTION: At least two installers are required due to the weight and size of the hood. 1. Measure from range top to hood bottom and mark line A. (26” minimum from range top) . 2. Plum and mark center line. Duct Cover Bracket 3.
- Page 12 www.windcrestcnp.com Display (speed level, delay of f, filter clean/replace) Blower On/Off Lights Normal/Dim/Off Speed Selection 15 Min Delay Off Blower On/Off By pressing , the blower is switched On and Off. When switched On, the blower will operate at the last setting before it was switched Off. When switched Off the entire hood powers Off, including the lights.
- Page 13 Charcoal Filter Change Reminder (charcoal filter, if installed) When your hood is installed as a recirculating unit, it is fitted with a set of charcoal filters to purify exhaust and fumes from cooking, then re-circulates the air within the home. These charcoal filters are required to be replaced after every 120 hours of use.
- Page 14 www.windcrestcnp.com Metal Filter Clean Reminder (metal mesh filter) Whether your hood is installed as an exhaust or purifying unit, a set if metal mesh filters are fitted by the factory, These metal mesh filters are intended to filter out residue from cooking. They need not be replaced on a regular basis but are required to be kept clean.
-
Page 15: Surface Maintenance
SURFACE MAINTENANCE: Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent , or steel wool/scouring pads which will scratch and damage surface. For heavier soil use liquid degreaser. After cleaning it is recommended that you use non-abrasive stainless steel polish/cleaners such as Stainless Steel Magic®, to polish and buff the stainless luster and grain. -
Page 16: Replacing Light Bulbs
www.windcrestcnp.com REPLACING LIGHT BULBS CAUTION: Light bulb becomes extremely hot when turned on. DO NOT touch bulb until switched off and cooled. Touching hot bulbs could cause serious burns. Make sure all power is turned off and bulbs are not hot. Remove by turning bulb counter clockwise. - Page 17 TROUBLESHOOTING PROCEDURES FOR WCG Issue Cause What to do After installation, 1. The power source is not turned ON. 1. Make sure the circuit breaker and the unit’s the unit doesn’t power is ON. work. 2. The power line and the cable locking connector 2.
- Page 18 www.windcrestcnp.com Wiring diagram label located through metal mesh fi lter opening on under side of unit body.
- Page 19 DESCRIPTION PART# Replacement Parts Light Bulb GU-10 50W (each) 11690.00 Metal Mesh Filter (each) 11691.00 Charcoal Filter (each) CF11688.00 Suction Cup S11557.00 Optional Accessories Recirculating Kit RECKITWCG Duct Cover Extension (up to 12’ ceiling) 12WCGEXT To order parts, visit us online at www.windcrestcnp.com or call us at 1.877.387.6721...
-
Page 20: Full One Year Warranty
7.) Service to replace consumable parts (i.e. Light Bulbs, Heat Lamps, Filters). 8.) Expenses for travel and transportation if appliance is located in a remote area. You may also write to us at: Wind Crest™ by CNP Industries, Inc. 351 Thor Place Brea, CA 92821 (877) 387-6721 This warranty applies to appliances used in residential applications only.
