SAFETY NOTICE ................LIST OF MATERIALS ..............INSTALLATION Ducting Calculation Sheet ........Mounting Height & Clearance ........ Ducting Options .......................... Electrical ................. Installing the One Piece Insert ......Insert Preparation ............FEATURES & CONTROLS Touch Controls 12-13 ............. RF Remote Control ............
Page 4 www.windcrestcnp.com READ AND SAVE THESE INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE CONTROL DEVICE. WARNING TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: a.
Page 5 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to Electrical Diagram on product. UIX3622S - 703W, 7 Amps UIX4822S - 773W, 7 Amps and install appropriate connector if necessary.
Page 6: Installation
MODELS: UIX3622S AND UIX4822S PARTS SUPPLIED 1 - Insert hood body 1 - 10” round duct collar 1 - Hardware package HARDWARE PACKAGE CONTENTS Light Bulb Removal #8 x 1/2” (12) Wire Caps (3) M4 x 6mm (4) Suction Cup (1)
Page 7 Equivalent number Equivalent number Duct pieces Duct pieces length x used T otal length x used T otal 3-1/ 4” x 10” 1 Ft. 6” Round 30 Ft. Rect., wall cap straight with damper 6” Round, 1 Ft. 6” Round, 30 Ft.
Page 8 www.windcrestcnp.com Minimum mount height between range top to hood bottom should be no less than 26”. Maximum mount height should be no higher than 36”. It is important to install the hood at the proper mounting height. Hoods mounted too low could mounted too high will be hard to reach and will If available, also refer range manufacturer’s height i n .
Page 9: Ducting Options
WARNING FIRE HAZARD NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. Use single wall rigid metal ductwork only. Some Ducting Options side wall cap w/ gravity damper side wall cap w/ gravity damper...
Page 10 www.windcrestcnp.com 3/4 View (34”)17- 1/4” (46“)23- ” (34”)12” (46“)18” elec. Top View (34”)12” (46“)18” elec. Back View...
Page 11: Electrical
ELECTRICAL WARNING how and background. For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not use extension cord or adapter plug with this appliance. Follow national electrical codes or prevailing local codes and ordinances. Electrical Supply: This appliance requires a 120V 60Hz electrical supply, and connected to an individual, properly grounded branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse.
Page 12 4. Lift insert into bottom opening of cabinet and secure to interior of WARNING: Make sure the surface you are securing the insert to is capable of holding the weight of UIX3622S or UIX4822S. FIG. 1 Failure to do so may cause personal injury or damage to cooking surface or counter.
Page 13 2. Remove grease tray by: 1) Pulling up on tray to front of insert. 2) release from bottom panel. 2) Lifting tray out of insert body. Bottom Panel Screws Locking Tabs 3. Remove left and right side spacer panels by 4.
Page 14: Lights
www.windcrestcnp.com Blower On/Off Display (speed level, delay off, filter clean) Lights On/Dim/Off Adjust 6 Speed Levels 5 Min Delay Off 1. Blower On/Off By pressing the blower is switched on and off. When switched on, the blower starts up on speed level 1. 2.
Page 15 Baffle Filter Clean Reminder A set of baffle filters are fitted by the factory, these baffle filters are intended to filter out residue from cooking. The filters need not be replaced on a regular basis but are required to be kept clean. The Baffle- Filter Clean reminder function in the microprocessor will automatically indicate by a flashing when the baffle filters need to be cleaned after every 30 hours of use.
Page 16: Maintenance
The RF remote control is equipped with a magnet on the back for easy storage. The remote may be placed on any magnetic surface such as a refrigerator or the Wind Crest remote holder, FIG. 3. The remote holder can be inserted into a standard electrical outlet for easy storage. Note: The remote holder does not charge the RF remote.
Page 17 SURFACE MAINTENANCE: Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent, or steel wool/ scoring pads which will scratch and damage surface. Do not use products containing chlorine bleach or orange cleaners. For heavier soil use liquid degreaser.
Page 18 Remove by turning bulb counter clockwise. Note: Bulb does not unscrew; it turns 60 degrees, stops and falls out. use a rubber/latex glove and turn counter clockwise. For Wind Crest part numbers please turn to page 19 of the manual. Bottom View...
Page 19: Troubleshooting
TROUBLESHOOTING PROCEDURES FOR UIX3622S & UIX4822S Issue Cause What to do After installation, 1. The power source is not turned ON. 1. Make sure the circuit breaker and the unit’s the unit doesn’t power is ON. work. 2. The power line and the cable locking connector 2.
Page 20 Blower Fan Curve Model: UIX3622S/UIX4822S AC Input: 120V, 60Hz Outlet Diameter: 10in 2.80 2.70 2.60 2.50 2.40 2.30 2.20 2.10 2.00 1.90 1.80 1.70 1.60 1.50 1.40 1.30 1.20 1.10 1.00 0.90 0.80 0.70 0.60 0.50 0.40 0.30 0.20 0.10...
Page 21 DESCRIPTION PART # Replacement Parts RF Remote Control S12313.00 Light Bulb Removal Suction Cup S11557.00 To order parts, visit us online at www.windcrestcnp.com or call us at 1.877.387.6721...
Page 22: Warranty
7.) Service to replace consumable parts (i.e. Light Bulbs, Heat Lamps, Filters). 8.) Expenses for travel and transportation if appliance is located in a remote area. You may also write to us at: Wind Crest™ by CNP Industries, Inc. 351 Thor Place Brea, CA 92821 (877) 387-6721 This warranty applies to appliances used in residential applications only.
