  • Page 1 VX Series Professional Loudspeakers Operation Manual...

  • Page 2: Important Safety Instructions

    Important Safety Instructions The lightning ash with arrowhead symbol within an Important Safety Instructions equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage " within the product's enclosure that may be of su cient magnitude to constitute a risk of electric shock to persons.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 2. Introduction...............................4 3. Unpacking and Visual Checks ........................4 3.1 Preliminary Recommendation ........................9 4. Connectors / Cabling ..........................5 5. Polarity Checking .............................6 6. Amplification and Power Handling ......................6 7. Crossover and Bi-amp Configuration ....................7 8.

  • Page 4: Introduction

    2. Introduction 2. Introduction Designed, engineered and built in the United Kingdom, the VX Series from Tannoy comprises a range of passive loudspeakers for demanding professional and commercial sound applications. At the heart of all VX Series loudspeakers is Tannoy’s acclaimed Dual Concentric driver technology.

  • Page 5: Connectors / Cabling

    30 A. When so equipped, the pins of the two speakON® sockets identified input/ output on the rear of the input panel are paralleled within the enclosure. Tannoy have adopted the conventional wiring standard for the VX Series product: pin 1+ is positive pin 1- is negative. For a worldwide list of Neutrik®...

  • Page 6: Polarity Checking

    5. Polarity Checking 5. Polarity Checking Checking the polarity of the wiring before the speaker system is mounted or flown will help ensure satisfactory performance. If you do not have a pulse based polarity checker, you may check LF units as follows: Connect two wires to the + and - terminals of a PP3 (9 V) battery.

  • Page 7: Crossover And Bi-Amp Configuration

    If higher peak outputs and additional low frequency output is required, then the VX Series can be used in conjunction with the Tannoy TX1 controller/crossover which provides high pass filtering and a degree of parametric equalisation, as well as a fixed crossover point for use with sub-bass loudspeakers (See the TX1 Operation Manual for further information.) The Tannoy TDX2 Digital controller will also perform the above...
  • Page 8 8. Equalisation Fig 1. Fig 2. VX Series Operation Manual rev 1.1.2...

  • Page 9: Equalisation

    8. Equalisation 8. Equalisation VX Series loudspeakers require no equalisation or correction to overcome system limitations; equalisation is necessary only to compensate for difficult acoustic environments. Over-equalisation can reduce system headroom and introduce phase distortion, resulting in degraded sound. If equalisation is required, it should be applied gently and smoothly.

  • Page 10: Arraying

    9. Arraying 9. Arraying Small alterations to loudspeaker positions can have the effect of minimising problematic combing frequencies. Arrays should be constructed so that the individual coverage patters of each loudspeaker combine with minimal overlap. The design of the VXP cabinet greatly simplifies the creation of effective arrays, allowing seamless wide horizontal coverage using two loudspeakers without the need for tedious experimentation.

  • Page 11: Dimensions

    10. Dimensions 10. Dimensions VX 5.2 180.0 200.0 50.8 37.0 [7.09"] [7.87"] [2.00"] [1.46"] 107.9 [4.25"] 333.0 [13.11"] 125.0 [4.92"] 75° 75° VX 5.2 VX 6 215.0 225.0 50.8 [8.46"] [8.86"] [2.00"] 37.0 [1.46"] 107.9 [4.25"] 333.0 [13.11"] 115.0 75°...
  • Page 12 10. Dimensions VX 8 280.0 275.0 50.8 [11.02"] [10.83"] [2.00"] 94.0 [3.70"] 107.9 [4.25"] 388.0 [15.28"] 180.0 [7.09"] 135.0 [5.31"] 60° 60° VX 8.2 VX 8 280.0 [11.02"] 140.0 [5.51"] 328.0 [12.91"] 590.0 [23.23"] 180.0 [7.09"] 145.0 60° 60° [5.71"] VX 8.2 VX Series Operation Manual rev 1.1.2...
  • Page 13 10. Dimensions VX 12 155.0 [6.10"] 370.0 360.0 70.0 [14.57"] [14.17"] [2.76"] 224.0 [8.82"] 127.0 [5.00"] 486.0 180.0 406.0 [19.13"] [7.09"] [15.98"] 290.0 [11.42"] 180.0 [7.09"] 190.0 [7.48"] 60° 40° VX 12 VX 12 HP 155.0 [6.10"] 370.0 360.0 70.0 [14.57"] [14.17"] [2.76"]...

  • Page 14: Rigging And Safety Procedures

    11. Rigging and Safety Procedures VX 12Q VX 12.2Q 40.0 370.0 190.0 155.0 [1.57"] [14.57"] [7.48"] [6.10"] 155.0 [6.10"] 180.0 [7.09"] 780.0 [30.71"] 292.0 [11.50"] 40.0 [1.57"] 290.0 [11.42"] 180.0 [7.09"] 190.0 60° 40° [7.48"] VX 12.2Q VX Series Operation Manual rev 1.1.2...
  • Page 15 11. Rigging and Safety Procedures VX 15HP VX 15.5Q VX Series Operation Manual rev 1.1.2...

  • Page 16: Rigging And Safety Procedures

    Tannoy Professional hardware has been designed for use with specific Tannoy Professional loudspeakers, and is not designed or intended for use with any other Tannoy Professional products, or any other devices. Using Tannoy Professional hardware for any purpose other than that indicated in this guide is considered to be improper use.

  • Page 17: Service Parts And Accessories

    11. Service Parts & Accessories 11. Service Parts & Accessories Model HF unit Dual driver Bass driver HF diapharagm Recone Kit VX 5.2 7900 0915 7900 1280 7900 1281 – – VX 6 7900 0683 7900 0742 – – –...

  • Page 18: Technical Specifications

    A full range of measurements, performance data, and EaseTM Data can be downloaded from www.tannoy.com. Tannoy operates with a policy of continuous research and development. Product performance always will equal or exceed published specifications. However, following introduction of new materials or manufacturing methods, Tannoy reserves the right to alter specifications without prior notice.
  • Page 19 A full range of measurements, performance data, and EaseTM Data can be downloaded from www.tannoy.com. Tannoy operates with a policy of continuous research and development. Product performance always will equal or exceed published specifications. However, following introduction of new materials or manufacturing methods, Tannoy reserves the right to alter specifications without prior notice.
  • Page 20 13. Technical Specifications Tannoy operates with a policy of continuous research and development. Product performance always will equal or exceed published specifications. However, following introduction of new materials or manufacturing methods, Tannoy reserves the right to alter specifications without prior notice.
  • Page 21 A full range of measurements, performance data, and EaseTM Data can be downloaded from www.tannoy.com. Tannoy operates with a policy of continuous research and development. Product performance always will equal or exceed published specifications. However, following introduction of new materials or manufacturing methods, Tannoy reserves the right to alter specifications without prior notice.

  • Page 22: Warranty

    No maintenance of the VX Series loudspeakers is necessary. All Tannoy VX Series professional loudspeaker products are covered by a 5 year warranty from the date of manufacture, subject to the absence of misuse, overload or accidental damage. Claims will not be considered if the serial number has been altered or removed.

  • Page 23: Declaration Of Conformity

    14. Declaration of Conformity 14. Declaration of Conformity The following apparatus is/are manufactured in the United Kingdom by Tannoy Ltd of Rosehall Industrial Estate, Coatbridge, Scotland, ML5 4TF and conform(s) to the protection requirements of the European Electromagnetic Compatibility Standards and Directives relevant to Domestic Electrical Equipment. The apparatus is designed...
  • Page 24 Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications. All specifications are subject to change without notice. Copyright (c) 2014 Tannoy Limited. All rights reserved.
