TOOLS AND MATERIALS REQUIRED

(NOT SUPPLIED)
Duct tape
Pencil and tape measure
Spirit level
Step ladder
Carpenter's square

REMOVE THE PACKAGING

• Remove the parts packages and packing materials.
• Lift the hood out of the box.
IMPORTANT:
the outside edges of the exhaust opening on the top.
Parts
Parts
Hood
Motor
Mounted
on Skid
Shipping Carton
• Place the hood on a protective surface to prevent
scratches and damage to the stainless steel finish.

Installation Preparation

Wire cutter/stripper
Safety glasses
Saber saw
or Sawsall
Pliers
Metal Snips
Lift the hood by grasping
Parts
7/16" Pivoting
hex socket with 4"
and 6" extensions
Key Hole Saw
Wire nuts
Flashlight
• Carefully, lay the hood on its side. A support frame is
secured to the inside top of the hood. Remove the
attachment screws at the outside top. Discard screws.
• Grasp the support
frame inside the
hood with both
hands and
carefully rotate out
of the opening.
Be careful not to
scratch the hood.
• The hood motor is shipped secured to the skid with 4
screws. Locate and remove 2 screws on each side of
the motor. Discard the shipping skid and screws.
8
Hammer
Electric or battery operated drill
and 3/16", bits, Phillips and Flat
Blade Screwdriver bits.
Phillips and flat blade
screwdrivers
120V 60Hz. 15 or 20 Amp,
2-wire with ground. Properly
grounded branch circuit.
10" round metal
duct, length to
suit installation.
Strain relief for
junction cover.
