- Page 1 Installation Instructions If you have questions, call 800-GE-CARES or visit our website at: www.monogram.com Island Vent Hoods Models: ZV42I ZV54I Monogram. ®...
-
Page 2: Before You Begin
Installation Instructions WARNING: BEFORE YOU BEGIN TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR Read these instructions completely and INJURY, OBSERVE THE FOLLOWING: carefully. A. Use this unit only in the manner intended by the • IMPORTANT – Save these instructions for local manufacturer. -
Page 3: Table Of Contents
Design Information CONTENTS Design Information Installation Instructions Product Dimensions ..............3 Step 1, Construct Ceiling Support ........10–12 Duct Cover Accessories ..............4 Step 2, Mount Template..............13 Product Clearances ..............4 Step 3, Size and Install Ductwork ..........13 Step 4, Install Support Frame and Duct Covers ....14 Advance Planning Step 5, Install Duct Transition and Damper ......15 Ductwork Planning ..............5... -
Page 4: Duct Cover Accessories
Design Information PRODUCT CLEARANCES DUCT COVER ACCESSORIES *Height to Ceiling 20" For ZV42 30" Min. 24" For ZV54 36" Max. 36" Min. ZV42I * 9" for ceiling heights 7’11" to 8’5" using the supplied support frame and duct cover. These vent hoods must be installed 30" min. to 36" max. Order ZX42DC10 for ceiling heights of 8"6"... -
Page 5: Advance Planning Ductwork Planning
Advance Planning ADVANCE PLANNING POWER SUPPLY Ductwork Planning IMPORTANT - (Please read carefully) • These vent hoods are equipped for 10” round WARNING: ductwork. • Determine the exact location of the vent hood. FOR PERSONAL SAFETY, THIS APPLIANCE • Plan the route for venting exhaust to the outdoors. MUST BE PROPERLY GROUNDED. -
Page 6: Installation Height
Advance Planning INSTALLATION HEIGHT REQUIREMENTS Model ZV42I Actual Chimney Length at Duct • These vent hoods must be installed 30" min. and 36" max. Ceiling Hood Installation Height Cover above the cooking surface – regardless of the ceiling Height 30" 31"... -
Page 7: Duct Fittings
Round roof cap 26 ft. * Actual length of straight duct plus duct fitting equivalent. Equivalent length of duct pieces are based on actual tests conducted by GE Evaluation Round Engineering and reflect requirements for good roof vent 24 ft. -
Page 8: Installation Preparation
Installation Preparation TOOLS AND MATERIALS REQUIRED 7/16" Pivoting (NOT SUPPLIED) hex socket with 4" Hammer and 6" extensions Duct tape Electric or battery operated drill Wire cutter/stripper and 3/16", bits, Phillips and Flat Key Hole Saw Blade Screwdriver bits. Pencil and tape measure 10"... -
Page 9: Parts, Hardware, Accessory Packages
Installation Preparation PARTS PROVIDED Locate the parts packed with the hood. Support frame for 8 ft. ceiling Transition with Damper with 4 large pan head screws installed on the bottom corners. Implement rods with standoffs 2-piece decorative duct cover Duct collar Decorative top cover 2 Filters (3 with 54"... -
Page 10: Installation Instructions
Installation Instructions STEP 1 CONSTRUCT CEILING SUPPORT Plan the Location of the Hood and Ductwork • The hood should extend beyond the front and rear edge • Use a plumb bob to check the location. The of the cooking appliance. countertop/cooktop below the hood must be centered •... - Page 11 Installation Instructions STEP 1 CONSTRUCT CEILING SUPPORT CONTINUED 12-3/4” (42” Hood) EXAMPLE B 17” (54” Hood) Install Cross- Framing 16” Joist Symmetrically About Spacing Duct/Cooktop Centerline 2x4 Cross Framing 10” Duct 8 5/8” Front Cooktop Align duct Hood Outline to center of Cooktop Top View –...
- Page 12 Installation Instructions STEP 1 CONSTRUCT CEILING SUPPORT CONTINUED • Secure each 2 x 4 block with at least four (4), #10 wood 2x 4 Min. screws, 3” long (not supplied). Use 8 wood screws Cross Framing total for the two supports. •...
-
Page 13: Step 2 Mount Template
Installation Instructions STEP 2 MOUNT TEMPLATE • Select the template for your hood size. • Align the template with the marks on the ceiling and tape in place. – Be sure the template is oriented correctly, with the front of the hood. •... -
Page 14: Step 4, Install Support Frame And Duct Covers
Installation Instructions STEP 4 INSTALL ACCESSORY (OR SUPPLIED) SUPPORT AND DUCT COV- Install Small Pan Head Screws on Each Side Top Duct Cover Screws D Bottom Duct Cover Adjust Install Frame to Install Stop Safety Screw Installation Screw on Each Side Height Screws E Stop Screw... -
Page 15: Step 5, Install Duct Transition And Damper
Installation Instructions STEP 5 INSTALL DUCT TRANSITION STEP 6 INSTALL HOOD WITH DAMPER Note: THREE PEOPLE ARE REQUIRED TO Bumper Pads COMPLETE THIS INSTALLATION! Duct Transition 1/4" Gap Attachment Screws Attachment Keyholes IMPORTANT: Remove shipping tape from damper and • Back out the hanging screws on the bottom of the check that damper moves freely. -
Page 16: Step 8 Connect Electrical
Installation Instructions STEP 8 CONNECT ELECTRICAL Verify that power is turned off at the source. • Install strain relief onto the knockout of the junction box. WARNING: If house wiring is not • Insert house wiring through strain relief and tighten. 2-wire with a ground wire, a ground must be provided •... -
Page 17: Step 10 Slide Duct Cover Down
Installation Instructions STEP 10 SLIDE DUCT COVER STEP 12 INSTALL RODS DOWN • Use a flat blade screwdriver to install stand-offs into SKIP THIS STEP IF USING THE SUPPLIED DUCT the bottom of the hood. COVER • Align implement rod to stand-offs with the screw hole towards the inside of the hood. -
Page 18: Step 13, Install Supplied Duct Cover, Top Cover
Installation Instructions STEP 14 FINALIZE INSTALLATION STEP 13 INSTALL SUPPLIED DUCT COVER AND TOP COVER • Check all lamps to assure tightness in sockets. • Turn power on at the circuit breaker. • Refer to the Owner’s Manual for operating and Install Duct cleaning instructions. -
Page 19: Step 15 Installation Checklist
Installation Instructions STEP 15 INSTALLATION CHECKLIST Check Blower Safety Screw Check appearance and installation Ensure that blower safety screw is securely tightened. Use a spirit level to check that the hood is level. See page 16, Step 9. If screw is missing, order Review installation instructions to determine source replacement parts bag. - Page 20 Note: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice. Monogram. ® GE Consumer Products Pub. No. 49-80209-1 General Electric Company Louisville, KY 40225 Dwg. No. 164D4290P361 © 2003 General Electric Company...
