Port Replicator

In addition to the ports available on the computer, a Port Replicator
(PA2731UE) provides audio line-in and line-out jacks, MIDI/joystick ports
and separate ports for PS/2 mouse and PS/2 keyboard. The Port
Replicator connects directly to the docking interface port on the back of the
computer so no cabling is necessary. The AC adaptor connects the Port
Replicator to a power source.
Before connecting, make sure the engaging pins are down.
Before connecting, remove the rubber cover from the computer's Docking
Interface cover.
Ports for connecting the following devices are available on the Port
Replicator. Connecting methods are explained later in this chapter.


External monitor


Parallel printer


Serial devices


PS/2 mouse


PS/2 keyboard


DC IN socket


Security lock slot


MIDI/Joystick


Audio line-in, line-out jacks


Headphone jack


Microphone jack


Volume control


Universal Serial Bus (two)
8-26 Optional Devices User's Manual
