Specifications are subject to change without notice or obligation.
Processor and Core Logic
Processor options
Processor packaging
Level 2 cache
Chipset-Northbridge
Chipset-Southbridge
Processor side bus speed
BIOS
System memory
Memory type
Memory expansion options
SPECIFICATIONS
®
One Mobile Intel
Pentium
To determine your notebook's processor, click Start, My Computer,
then click View System Information. The processor is listed.
Intel socketable u-FCPGA
2 MB
Intel 915PM
Intel ICH6-M
400 or 533 MHz
Phoenix BIOS
■
512 KB Flash ROM with Boot Block Support
■
SMBIOS 2.3 support
■
Advanced Configuration and Power Interface 2.0 (ACPI 2.0)
■
support
Wired for Management 2.0 (WfM 2.0)
■
400 or 533 MHz DDR2 RAM
Two 200-pin industry standard DDR2-SODIMM socket, user
■
accessible
2 GB maximum system memory
■
To determine your notebook's memory, click Start, My Computer,
then click View System Information. The memory is listed.
www.gateway.com
Gateway 8000 Series
Notebook
®
M CPU
1
Advertisement
Related Manuals for Gateway 8000 Series
Summary of Contents for Gateway 8000 Series
-
Page 1: Specifications
SPECIFICATIONS Gateway 8000 Series Notebook Specifications are subject to change without notice or obligation. Processor and Core Logic ® ® Processor options One Mobile Intel Pentium M CPU To determine your notebook’s processor, click Start, My Computer, then click View System Information. The processor is listed. - Page 2 Software control provided through Windows ■ Internal speakers Stereo speakers built into the front of notebook ■ 1.0 W maximum output for each channel ■ Internal microphone Omni-directional, low impedance Audio jacks Stereo headphone output ■ Stereo microphone input ■ www.gateway.com...
- Page 3 Full-sized 84-keys ■ Full-sized 21-key keypad ■ 19 mm × 19 mm key pitch ■ 3.0 mm keystroke ■ Pointing device Gateway EZ-Pad™ touchpad with vertical scroll ■ 2-button design ■ Status indicators AC power ■ Wireless Ethernet ■ Caps lock ■...
- Page 4 S-Video TV out ■ Four USB 2.0 (4-pin) ■ External monitor (VGA) ■ Parallel ■ High-speed serial ■ IEEE 1394 (4-pin) ■ Stereo headphone output ■ Stereo microphone input ■ Docking port ■ DC input ■ Security Kensington lock loop www.gateway.com...
- Page 5 A DVD logo in combination with a CD-R/RW logo indicates a DVD drive that also is a recordable/rewritable CD drive, and a DVD ReWritable logo in combination with a CD-R/RW logo indicates a recordable/rewritable DVD drive that also is a recordable/rewritable CD drive. www.gateway.com...
- Page 6 Lid switch LCD On/Off, Standby, Hibernate Security Passwords Power-on password (user/supervisor password set in BIOS) ■ Hard drive password ■ Physical Main system memory compartment screws ■ Hard drive cover screw ■ ® Kensington security slot on notebook back ■ www.gateway.com...
- Page 7 Operating temperature F to 90 F (10 C to 32 ° ° ° ° Storage temperature F to 140 F (-15 C to 60 Operating humidity 20% to 80% relative humidity; no condensation MAN 8000 SER SONIC SPECS R0 3/05 www.gateway.com...
