  • Page 1 OPERATOR'S MANUAL THD SATELLITE COMPASS SC-110 MODEL www.furuno.co.jp...
  • Page 2 The paper used in this manual is elemental chlorine free. ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN Telephone : +81-(0)798-65-2111 : +81-(0)798-65-4200 A : FEB 2004 Printed in Japan All rights reserved. F : FEB . 08, 2011 Pub. No. OME-72570-F...
  • Page 3 (http://www.eiae.org/) for the correct method of disposal. How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery, see the chapter on Maintenance. Follow the instructions below if a battery is used. Tape the + and - terminals of battery before disposal to prevent fire, heat generation caused by short circuit.

  • Page 4: Safety Instructions

    A warning label is attached to the processor unit. Do not remove the label. If the label is missing or No one navigation device should ever damaged, contact a FURUNO agent or dealer be solely replied upon for the about replacement.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FOREWORD........................v SYSTEM CONFIGURATION ..................vi EQUIPMENT LIST ......................vii SPECIFICATIONS ..................... SP-1 1 INSTALLATION ....................... 1-1 1.1 Mounting Considerations....................1-1 1.1.1 Antenna unit......................1-1 1.1.2 Display unit, processor unit..................1-3 1.2 Installing the Antenna Unit....................1-4 1.3 Installing the Processor Unit....................
  • Page 6 2.9.4 Time format ......................2-15 2.9.5 Demonstration mode ..................... 2-16 2.10 WAAS/DGPS Setup ......................2-17 2.11 OTHERS Menu ......................... 2-19 2.12 TRIP Menu ........................2-20 2.13 Resetting Distance Run ..................... 2-21 2.14 Choosing External Heading Source for Backup ..............2-21 3 MAINTENANCE, TROUBLESHOOTING ..............

  • Page 7: Foreword

    FURUNO Electric Company thanks you for purchasing the FURUNO SC-110 THD Satellite Compass. (Hereafter, for sake of brevity, we refer to SC-110 as Satellite Compass.) We are confident you will discover why the FURUNO name has become synonymous with quality and reliability.

  • Page 8: System Configuration

    SYSTEM CONFIGURATION The SC-110 consists of an antenna, a display unit and a processor unit. The tri-antenna system helps reduce the influence of ship's motion (rolling). Antenna Unit SC-1203F Display Unit SC-502 Analog pitch 6 ports for Heading or Navigation Data Processor Unit Analog roll (5 AD-10/IEC 61162 ports, 1 AD-10 port)

  • Page 9: Equipment List

    EQUIPMENT LIST Standard supply Name Type Code No. Remarks GPS Antenna SC-1203F  Radome type Display Unit SC-502  Processor Unit SC-1101  CP20-02230* 004-378-110 TPPX cable CP20-02260* 004-379-660 TNC cable CP20-02241* 004-378-200 For antenna unit For processor unit: Installation CP20-02600 000-041-905 CP20-02601*,...
  • Page 10 This page intentionally left blank. viii...

  • Page 11: Specifications

    FURUNO SC-110 SPECIFICATIONS OF SATELLITE COMPASS SC-110 GENERAL Heading accuracy 0.3° RMS (95% static accuracy) Heading resolution 0.1° Follow-up 45°/s rate-of-turn Settling time 4 minutes Position accuracy 10 m, or 5 m (DGPS), 95% of the time Heading/ Nav data output...
  • Page 12 FURUNO SC-110 COATING COLOR Display unit Panel: N3.0, Chassis: 2.5GY5/1.5 Processor unit 2.5GY5/1.5 Antenna unit N9.5 SP - 2 E7257S01E...

  • Page 13: Installation

    INSTALLATION Mounting Considerations 1.1.1 Antenna unit General Keep the length of the antenna cable in mind when selecting a mounting location. Installing the antenna above superstructures The antenna must be mounted above all other structures on the vessel to obtain an unobstructed view of the satellites regardless of vessel heading. Failure to do so will cause shadows and multipath reflection problems.
  • Page 14 1. INSTALLATION The horizontal separation between the antenna and masts must be as follows: Mast diameter Separation distance (minimum) 10 cm 1.5 m 30 cm ° ° SC-series Antenna ° Less than 10 Mast, etc. Separation degrees Keep the length of antenna cable in mind when selecting a mounting location. The cable comes in lengths of 15 meters (standard supply), or 30 m or 50 m (optional lengths).

  • Page 15: Display Unit, Processor Unit

    1. INSTALLATION Location influenced Radar Antenna by reflected wave. Reception blocked by mast. SC-series Antenna Bridge Example of antenna installed below superstructures 1.1.2 Display unit, processor unit Choose a location where vibration and shock are minimal. Install the units well away from locations subject to rain and water splash. Locate the units away from air conditioner vents.

  • Page 16: Installing The Antenna Unit

    1. INSTALLATION Installing the Antenna Unit Note: “Bird-repellent fixtures” may be attached to each antenna element and the center cover to prevent birds from alighting on them. If it is more convenient to attach them before fixing the antenna unit to the mounting location, do step 7 before fixing the antenna unit.
  • Page 17 1. INSTALLATION 2. Fix the antenna unit to the post as shown below. Fix the #1 and #2 antennas on Set the antenna the fore-and-aft line of the ship, unit to the flange. with the #2 antenna forward of the #1 antenna. Flat washer Spring washer (Torque: 29.58 Nm)
  • Page 18 1. INSTALLATION 3. Coat each nut, bolt and washer with silicone rubber for waterproofing. Coat bolt, nut and washer completely with silicone rubber. Coating bolt, nut and washer with silicone rubber 4. As shown below, make a loop in the antenna cable and fasten the antenna cable to the antenna post with two cable ties.

  • Page 19: Installing The Processor Unit

    1. INSTALLATION Installing the Processor Unit The processor unit should be mounted aligned with the ship’s fore-and-aft line. It can be mounted on the deck, bulkhead, or on the underside of a desk. Choose a mounting location which allows you to easily view the power lamp on the top of the unit and which is within 2.5 of the ship’s fore-and-aft line.

  • Page 20: Deck Mount

    1. INSTALLATION 1.3.2 Deck mount Orient the processor unit as shown below and fix it to the mounting location with four tapping screws (M5x20). You will set the orientation later on the menu. Mount processor unit Reference Direction so reference direction is within ±...

  • Page 21: Installation On The Underside Of A Desk

    1. INSTALLATION 1.3.3 Installation on the underside of a desk The processor unit may be mounted on the underside of a desk as shown in the figure below. Do not install it on the overhead. Desk Name Plate Installation of processor unit on the underside of a desk Reference Direction Mount processor unit so reference direction is...

  • Page 22: Installing The Display Unit

    1. INSTALLATION Installing the Display Unit The display unit can be installed on a desktop, overhead, or flush mounted in a console. The optimal viewing distance is 0.5 m. 1.4.1 Desktop, overhead mounting 1. Fasten the hanger to the mounting location with four tapping screws (supplied).
  • Page 23 1. INSTALLATION Flush mount “S” Flush mount “S” kit Type: OP20-17, Code No.: 000-040-720) Name Type Code No. Flush Mount Fixture 20-007-2401 100-183-190 Wing Bolt M4X30 000-804-799 Wing Nut 000-863-306 Hex Bolt M6X12 000-862-127 Spring Washer 000-864-260 1. Make a cutout in the mounting location. The dimensions are 167(W) x 92(H) 2.

  • Page 24: Wiring

    1. INSTALLATION Wiring This section covers general wiring. For further details see the interconnection diagram at the back of this manual. ANTENNA UNIT SC-1203F PROCESSOR UNIT SC-1101 DPYC 1.5 12-24 VDC TPPX6-3D2V-15M, 15m MJ-A7SPF0006-100, TNC-PS-3D-15 (3 pcs.) DISPLAY UNIT SC-502 GPS ANT DISPLAY ANTENNA Terminals...
  • Page 25 1. INSTALLATION Note 1: Use cable type DPYC-1.5 (or equivalent) for the power cable. DPYC-1.5 Armor Sheath 11.7 mm Conductor S = 1.5 mm = 1.56 mm Sectional view of coaxial cable DPYC-1.5 Note 2: The optional antenna cable set (CP20-01700 or CP20-01710) allows you to extend antenna cable length to 30 m (50 m).
  • Page 26 1. INSTALLATION How to attach connector N-P-8DFB Outer Sheath Armor Inner Sheath Shield (Dimensions in millimeters.) Cover with heat-shrink tubing and heat. Cut off insulator and core by 10 mm. Twist shield end. Slip on clamp nut, gasket and clamp as shown left. Clamp Clamp Nut Gasket (reddish...

  • Page 27: Initial Settings

    1. INSTALLATION Initial Settings Follow the procedures in this section to enter initial settings. NOTICE Improper menu settings may stop output of data and display the message "RATE ERROR." Be sure to enter correct data. 1.6.1 Confirming satellite status Press the [SAT STATUS] key. Satellites used for measurement "OK"...

  • Page 28: Choosing Mounting Method

    1. INSTALLATION 1.6.2 Choosing mounting method 1. Turn on the processor unit and then press the [MENU] key to show the menu. MAIN MENU SATELLITE ALARMS WAAS/DGPS MESSAGES I/O SETUP GPS SETUP INST MENU SYS SETUP ERASE SOFT VER. TRIP MENU OTHERS Main menu 2.

  • Page 29: Connection Of External Equipment

    1. INSTALLATION Connection of External Equipment 1.7.1 General wiring All external equipment are terminated on the MAIN Board inside the processor unit. Turn off the power and unfasten four screws to remove the cover. Connect wiring from external equipment referring to the interconnection diagram. Use the opener supplied to open terminal blocks, referring to the instructions below.

  • Page 30: Fabrication Of Cables

    1. INSTALLATION 1.7.2 Fabrication of cables Cable Sectional view, fabrication Power cable DPCY-1.5 Armor Sheath Armor Sheath equivalent) Cut the sheath. φ = 11.7 mm Conductor S = 1.5 mm φ = 1.56 mm SECTIONAL VIEW Vinyl tape Crimp-on lug Lay in clamp FV1.25-5 where paint...

  • Page 31: Operation

    OPERATION Controls MENU key: Opens menu. Omnipad: Selects menu items; shifts cursor. DISP key: Selects display; closes menu. MENU ENT key: Terminates key input. DISP DIM key: Adjusts panel illumination, display contrast. SETUP HDG SETUP key: Chooses heading SATELLITE COMPASS STATUS source.

  • Page 32: Turning The Power On/Off

    2. OPERATION Turning the Power On/Off Use the power switch on the processor unit to turn the power to the display unit on and off. POWER Switch Processor unit A beep sounds and the display starts up with the last-used display. Note: If backup heading data is used the heading indication flashes until faithful heading data becomes available.

  • Page 33: Choosing A Display

    2. OPERATION Choosing a Display Use the [DISP] key to show a display desired. 2.4.1 Description of displays Heading display The heading display shows heading, course, speed, date, time and position-fixing status. The heading status mark changes in the sequence shown below.
  • Page 34 2. OPERATION Steering display The steering display shows heading in digital and analog form. SOG and COG are also indicated. Note that COG accuracy is low when the own ship speed is low. The faster the speed, the more accurate the COG. 07:54:30 °...
  • Page 35 2. OPERATION Speed display Depending on the setting of DISTANCE DISP on the TRIP menu, the Set and Drift display or the Distance Run display is shown. The current indication requires a Doppler Speed Log. Ground speed 07:54:30 07:54:30 Lateral speed Speed relative to...

  • Page 36: Alarm Setup

    2. OPERATION Alarm Setup The SC-50 can alert you with audible and visual alarms when GPS signal, DPGS signal and WAAS signal are lost. To set the DGPS alarm, do the following: 1. Press the [MENU] key to show the menu. 2.

  • Page 37: Confirming Satellite Status

    2. OPERATION Confirming Satellite Status You can check the receiving condition of each antenna unit as follows: 1. Press the [MENU] key to open the menu. 2. Choose SATELLITE and then press the [ENT] key. RX signal level Horizontal bar extends with signal strength.

  • Page 38: Gps Setup

    2. OPERATION GPS Setup The GPS SETUP menu smoothes position and course, averages speed, applies position offset, and deactivates unhealthy satellites. 2.7.1 Displaying the GPS setup menu 1. Press the [MENU] key to open the menu. 2. Choose GPS SETUP and then press the [ENT] key. GPS SETUP SMOOTH POS 0SEC...

  • Page 39: Output Data

    2. OPERATION DISABLE SV (Disable satellite) Every GPS satellite is broadcasting abnormal satellite number(s) in its Almanac, which contains general orbital data about all GPS satellites. Using this information, the GPS receiver automatically eliminates any malfunctioning satellite from the GPS satellite schedule. However, the Almanac sometimes may not contain this information.
  • Page 40 GNS: GNSS fix data GLL: Geographic position, latitude/longitude VHW: Water speed and heading VBW: Dual ground/water speed HVE: GPS antenna up-down motion amplitude (FURUNO proprietary sentence) ZDA: Time and date RMC: Recommended minimum specific GNSS data 7. Use the Omnipad to choose OFF or ON as appropriate and then press the [ENT] key.
  • Page 41 2. OPERATION 11. Use the Omnipad to choose the baud rate of the equipment connected and then press the [ENT] key. 12. INTERVAL is selected; press the [ENT] key. 25ms 100ms 200ms 20ms Tx interval options 13. Use the Omnipad to choose appropriate output interval and then press the [ENT] key.
  • Page 42 2. OPERATION Output sentence limitation The number of sentences which can be output depends on baud rate and output interval settings. The maximum number of characters per each data sentences are shown in the table below and the total number of characters must satisfy the formula shown below.

  • Page 43: Log Pulse

    2. OPERATION 2.8.2 Log pulse This equipment provides SOG (speed over ground) in high accuracy. It converts an SOG value to a pulse signal and outputs at the rate of 200 or 400 pulses/NM. 1. Press the [MENU] key. 2. Choose I/O SETUP and then press the [ENT] key. 3.

  • Page 44: System Setup

    2. OPERATION System Setup 2.9.1 Geodetic data Your unit is preprogrammed to recognize most of the major chart systems of the world. Although the WGS-84 system (default setting) is the GPS standard, other categories of charts in other datum still exist. Match the GPS datum with the chart system you use.

  • Page 45: Units Of Measurement

    2. OPERATION 2.9.2 Units of measurement Distance/speed can be displayed in nautical miles/knots, kilometers/kilometers per hour, or miles/miles per hour. 1. Press the [MENU] key to open the menu. 2. Choose SYS SETUP and then press the [ENT] key. 3. Choose UNITS. 4.

  • Page 46: Demonstration Mode

    2. OPERATION 2.9.5 Demonstration mode The demonstration mode provides simulated operation of the equipment. 1. Press the [MENU] key to open the menu. 2. Choose SYS SETUP and then press the [ENT] key. 3. Choose DEMO and then press the [ENT] key. 4.

  • Page 47: Waas/Dgps Setup

    2. OPERATION 2.10 WAAS/DGPS Setup 1. Press the [MENU] key to open the menu. 2. Choose WAAS/DGPS and then press the [ENT] key. STATION: Shows GOOD or NG. WAAS/DGPS DATA: Shows GOOD or NG. SIG. S: Signal Strength. A figure be tween 0 MODE and 99 is shown.
  • Page 48 2. OPERATION 2) Use the Omnipad to choose WAAS satellite search method, AUTO or MANUAL as appropriate. For MANUAL, press the [ENT] key, enter WAAS satellite number, referring to page AP-14 (7. What is WAAS?) and then press the [ENT] key. 3) CORRECTIONS DATA SET is selected;...

  • Page 49: Others Menu

    2. OPERATION 2.11 OTHERS Menu The OTHERS menu contains the following items: HOLD HDG DATA: Choose whether to display last-used heading data at power on or not. This data is not reliable. HDG RESTORATION: Choose how to restore GPS signal, automatically or manually, after it is lost.

  • Page 50: Trip Menu

    2. OPERATION 2.12 TRIP Menu The TRIP menu functions to • Choose the indication to show on the SOG/STW display • Choose source of distance run • Reset distance run to zero • Smooth the tide drift indication • Enter smoothing for rate of turn and display range scale 1.

  • Page 51: Resetting Distance Run

    2. OPERATION 2.13 Resetting Distance Run The distance run may be reset to zero as below when the source of distance run is GPS or VBW. 1. Press the [MENU] key to display the main menu. 2. Choose TRIP MENU and then press the [ENT] key. 3.
  • Page 52 2. OPERATION This page is intentionally left blank. 2-22...

  • Page 53: Maintenance, Troubleshooting

    MAINTENANCE, TROUBLESHOOTING WARNING NOTICE ELECTRICAL SHOCK HAZARD Do not apply paint, anti-corrosive Do not open the equipment. sealant or contact spray to coating or plastic parts of the equipment. Only qualified personnel Those items contain organic solvents that should work inside the can damage coating and plastic parts, equipment.

  • Page 54: Troubleshooting

    3. MAINTENANCE, TROUBLESHOOTING Troubleshooting This section provides basic troubleshooting procedures which the user may follow to restore normal operation. Troubleshooting Symptom Cause Remedy Cannot turn on the power. Power connector on the Firmly connect the power processor unit connector. Power supply failure Check the power supply.

  • Page 55: Diagnostics

    3. MAINTENANCE, TROUBLESHOOTING Diagnostics Diagnostic test1 The diagnostic test1 checks the equipment for proper operation. Note: Heading is not output during the diagnostic test, and this is communicated with an appropriate message. After completing the diagnostic test, turn the power off and on to update heading data. 1.
  • Page 56 3. MAINTENANCE, TROUBLESHOOTING OK shown for normal; ROM RAM NG (No Good) shown for error GPS1 PUSH KEY GPS receiver GPS2 KEY TEST GPS3 Press each key one by Processor unit one. Pressed key’s name Display unit DISP appears here if key is functioning properly.
  • Page 57 3. MAINTENANCE, TROUBLESHOOTING Diagnostic test2 If the heading indication changes randomly when ship is at anchor or does not change when the ship moves, run the test2 following the procedure below, with the ship at anchor and satellite signal received. Note: Heading is not output during the diagnostic test, and this is communicated with an appropriate message.
  • Page 58 3. MAINTENANCE, TROUBLESHOOTING Diagnostic test3 This test checks the buzzer signal/contact for proper operation. 1. Press the [MENU] key to open the menu. 2. Choose SYS SETUP and then press the [ENT] key. 3. Choose TEST? and then press the [ENT] key. TEST1 TEST2 TEST3...

  • Page 59: Program Number

    3. MAINTENANCE, TROUBLESHOOTING Program Number You may display the program number as follows: 1. Press the [MENU] key to open the menu. 2. Choose SOFT VER. and then press the [ENT] key. SOFTWARE VERSION DISPLAY 205-1342-**.** PROCESS 205-1341-**.** GPS1 4850263*** GPS2 4850263*** GPS3...

  • Page 60: Replacement Of Battery

    3. MAINTENANCE, TROUBLESHOOTING Replacement of Battery The processor unit has a battery that stores data when the power is turned off. When the battery voltage is low, the message “BATTERY!” appears on the display. Have a qualified technician replace the battery, following the procedure below.

  • Page 61: Replacement Of Fuse

    3. MAINTENANCE, TROUBLESHOOTING Replacement of Fuse The 3 A fuse on the POWER Board inside the processor unit protects the equipment from overcurrent and reverse polarity of the power supply. If the fuse blows, have a qualified technician check the fuse. WARNING Use the proper fuse.
  • Page 62 3. MAINTENANCE, TROUBLESHOOTING Error messages (con’t from previous page) Error Message Meaning Remedy BATTERY ALM! Voltage of battery in processor Have battery replaced at unit is low. earliest convenience. DATA ERR!* GPS data (from the GPS receiver Check GPS receiver. in the processor unit) is lost for one minute.

  • Page 63: Appendix

    APPENDIX 1. Menu Tree BUZZER (SHORT, LONG, CONSTANT) ALARMS MENU DGPS (OFF, ON) MESSAGES SMOOTH POS (0 SEC) GPS SETUP SMOOTH S/C (5 SEC) LAT OFFSET (0.000'N) LON OFFSET (0.000'E) DISABLE SV DATUM (WGS84, WGS72, OTHER 001 (WGS84)) SYS SETUP UNITS (kn , km/h, mi/h) TIME DIFF (+00:00) TIME DISP (12 HOUR, 24 HOUR)

  • Page 64: Digital Interface

    APPENDIX 2. Digital Interface Output sentences of channel 1 DATA OUT1-5: HDT, HDM, THS, ROT, Patt, Phve, VTG, GGA, GLL, GNS, ZDA, VHW, VBW, VDR DATA OUT 6: AD-10 Transmission interval HDT, HDM, THS, ROT, Patt, Phve: 100 ms VTG, GGA, GLL, GNS, ZDA, VHW, VBW, VDR: 1 s For details see page 2-12.
  • Page 65 APPENDIX Schematic diagrams Data IN Load requirements Isolation: Optocoupler Input Impedance: 440 ohm Max. voltage: ±15V Data Out 1-6 Output drive capability Max : 10mA AP-3...
  • Page 66 APPENDIX Data sentences PFECatt- True heading, pitching, rolling $PFEC,GPatt,xxx.x,+xx.x,-xx.x<CR><LF> (Ver. 1.5) $PFEC,GPatt,xxx.x,+xx.x,-xx.x*hh<CR><LF> (Ver. 2.0) Checksum (Ver. 2.0) Rolling (output to tenths place) Pitching (output to tenths place) Heading, true (output to tenths place) GGA - Global positioning system (GPS) fix data Time, position and fix related data for a GPS receiver.
  • Page 67 APPENDIX GNS - GNNS fix data $--GNS,hhmmss.ss,llll.lll,a,yyyyy.yyy,a,c--c,xx,x.x,x.x,x.x,x.x,x.x*hh<CR><LF> +--- 11 +------ 10 +---------- 9 +-------------- 8 +------------------ 7 | +---------------------- 6 +------------------------- 5 | +------------------------------ 4 +-------+--------------------------------- 3 +---+--------------------------------------------- 2 +------------------------------------------------------------- 1 1. UTC of position 2. Latitude, N/S 3. Longitude, E/W 4.
  • Page 68 APPENDIX RMC – Recommended minimum specific GNSS data $GPRMC,hhmmss.ss,A,llll.ll,a,yyyyy.yy,a,x.x,x.x,ddmmyy,x.x,a,a*hh<CR><LF> 2 3 4 6 7 8 10 11 12 1. UTC of position fix (000000 - 235959) 2. Status (A=data valid, V=navigation receiver warning) 3. Latitude (0.0000 - 9000.0000) 4. N/S 5.
  • Page 69 APPENDIX VHW - Water speed and heading The compass heading to which the vessel points and the speed of the vessel relative to the water. $GPVHW,x.x,T,x.x,M,x.x,N,x.x,K,*hh <CR><LF> 1 2 3 4 5 6 7 8 1. Heading, degrees (0.0 - 359.9, NULL) 2.

  • Page 70: Input/Output Ports

    200ms, 1s, 2s, 20ms, selectable), VTG, GGA, GLL, GNS, ZDA, VHW, VBW, VDR, RMC : (1s, 2s, selectable) ATT sentence Proprietary sentence or FURUNO sentence Only P sentence : output rate of 25ms, 100ms,200ms, 1s, 2s, 20ms, selectable ATT sentence – True heading, pitching, rolling $PFEC,GPatt,xxx.x, +xx.x, +xx.x<CR><LF>...
  • Page 71 APPENDIX Port Terminal Name Signal Remarks Label DATA WAGO Heading AD-10 only OUT6 231-304/026-000 AD-10 output interval: 25ms LOG/ WAGO 200 pulse/NM or 400 pulse/NM (software), ALARM 0.5A max. 231-306/026-000 Signal Heading alarm, 0.5A max, normal close alarm DATA IN WAGO Heading Heading data in either AD-10 or...

  • Page 72: Parts List And Parts Location

    This equipment contains complex modules in which fault diagnosis and repair down to component level are not practical (IMO A.694(17)/8.3.1. Only some discrete components are used. FURUNO Electric Co., Ltd. believes identifying these components is of no value for shipboard maintenance; therefore, they are not listed in the manual. Major modules can be located on the parts location photo on this page.

  • Page 73: Geodetic Chart Codes

    APPENDIX 5. Geodetic Chart Codes 001：WGS84 087：MAPARIMA, BWI ：Trinldad and Tobago 002：WGS72 088：NORTH AMERICAN 1927 ：Western United States 003：TOKYO ：Mean Vallue (Japan, Korea, and Okinawa) 089： ：Eastern United States 004：NORTH AMERICAN 1927 ：Mean Vallue (CONUS) 090： ：Alaska 005：EUROPEAN 1950 ：Mean Vallue 091：...

  • Page 74: What Is Waas

    APPENDIX 6. What is WAAS? WAAS, available in North and South America mainly, is a provider in the worldwide SBAS (Satellite Based Augmentation System) navigation system. SBAS provides GPS signal corrections to SBAS users, for even better position accuracy, typically better than three meters.

  • Page 75: Terminology, Units Of Measurement, Symbols

    APPENDIX 7. Terminology, Units of Measurement, Symbols Terminology Term Meaning Term Meaning Automatic Identification Heading System ALARM Alarm Identification Alarm IEC ED1 IEC 61162-1 Edition 1 (NMEA 0183 Version 2.0) Antenna IEC ED2 IEC 61162-1 Latest Edition (NMEA 0183 Latest Version) April ARPA Automatic Radar Plotting...
  • Page 76 APPENDIX Term Meaning Term Meaning Random Access Memory Speed Over Ground Read Only Memory Speed Through the Water Rate of Turn Satellite Receive True South TEST Test Satellite Transmitting Heading Device Satellite Compass TIME Time second Transmit Universal Time, Coordinated September Version Signal...
  • Page 82 Takahashi T...

  • Page 87: Interconnection Diagram

    相互結線図 ＊５）メニュー切替。 *5. SELECT FROM MENU. 19/Jan/2011 ＊６）方位出力が停止したとき、接点回路がオープンになる。 *6. IF THE HEADING OUTPUT STOPS, THE CONTACT CIRCUIT OPENS. SCALE MASS NAME SATELLITE COMPASS ＊７）ケーブルクランプでアースを取る。 *7. GROUND THROUGH CABLE CLAMP. DWG.No. REF.No. INTERCONNECTION DIAGRAM C7257-C01- H 20-024-5000-3 FURUNO ELECTRIC CO., LTD.

  • Page 88: Index

    INDEX Alarms menu .......... 2-6 Maintenance battery replacement ......3-8 cleaning ..........3-1 Battery replacement ....... 3-8 fuse replacement ........3-9 Menu tree ..........AP-1 Compass display ........2-4 Control description ......... 2-1 Nav data display ........2-3 Data clearing .......... 3-7 OTHERS menu........2-20 Demonstration mode ......
