Monitor menu

The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
Scroll down to display the other BIOS items.
UEFI BIOS Utility - Advanced Mode
Ai Tweaker
Main
CPU Temperature
MB Temperature
VCORE Voltage
3.3V Voltage
5V Voltage
12V Voltage
VDDA2.5V Voltage
CPU Fan Speed
CPU OPT Fan Speed
Chassis Fan 1 Speed
Chassis Fan 2 Speed
Chassis Fan 3 Speed
Chassis Fan 4 Speed
CPU Q-Fan Control
CPU Temperature / MB Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU and motherboard
temperatures. Select Ignore if you do not wish to display the detected temperatures.
VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage, VDDA2.5V Voltage
The onboard hardware monitor automatically detects the voltage output through the onboard
voltage regulators. Select Ignore if you do not want to detect this item.
CPU Fan Speed [xxxx RPM] or [Ignore] / [N/A], CPU OPT Fan Speed [xxxx
RPM] or [Ignore] / [N/A], Chassis Fan 1/4 Speed [xxxx RPM] or [Ignore] / [N/A]
The onboard hardware monitor automatically detects and displays the CPU, chassis,
and power fan speed in rotations per minute (RPM). If the fan is not connected to the
motherboard, the field shows N/A. Select [Ignore] if you do not wish to display the detected
speed.
CPU Q-Fan Control [Enabled]
[Disabled] Disables the CPU Q-Fan control feature.
[Enabled] Enables the CPU Q-Fan control feature.
ASUS SABERTOOTH 990FX/GEN3 R2.0
