Page 1: Quick Start Guide
® PRIMUX Series PRIMUX-16X64 PRIMUX-8X32 KVM Matrix Switch via CATx Quick Start Guide PRIMUX-16X64 (Front and Rear View) HA-UNV PS/2 and USB Host PRIMUX-UZR Adapter (sold separately) User Station (sold separately) -
Page 2: What's In The Box
What's in the Box Terminating Plug NTI PRIMUX-16X64 or 8X32 Cat5 KVM Matrix Switch AC Line Cord Country Specific Manual CD Quick Start Guide What's also needed (sold separately) NTI Host Adapter(s) HA-UNV PS2/USB Host Adapter (Includes a CT7038 USB-PS2 Adapter)/ •... -
Page 3: Hardware Setup
Hardware Setup 1. Disconnect power from each CPU to be connected. (If your CPU fully supports hot-plugging, powering-down will not be necessary). 2. Plug the appropriate Host Adapter into the devices and video ports on the back of each CPU. 6 miniDIN male connectors 6 pin miniDIN... -
Page 4: Usb Keyboard
Cable to CPU 3. Connect a CAT5 cable from the "OUT" port on each Host Adapter to a "CAT5" port on the PRIMUX KVM Matrix Switch. 4. Connect the Terminating Plug (supplied with Host Adapter) to the "IN" port on each Host Adapter. WARNING: Never connect the PRIMUX Host Adapter, User Station, or Matrix Switch to an Ethernet card, Ethernet router, hub or switch or other Ethernet RJ45 connector of an Ethernet device. - Page 5 7. Connect a Cat5 cable between the “Cat5” port on the User Station and a “User” port on the Matrix Switch. Rear View of PRIMUX-Matrix Switch USER EXPANSION PORT ETHERNET RS232 USER NETWORK TECHN OLOGIES INC Tel: 330-562-7070 1275 Dan ner Dr, Au ro ra, OH 44202 www.nti1.com Rear View of PRIMUX-UZR User Station Rear View of PRIMUX-UZR User Station...
-
Page 6: Initial Startup
Initial Startup Upon startup, the Command Mode On Screen Display (OSD) menu will be displayed, auto-logging you in as the administrative user “root” root . By default, the user “ ” has full administrative rights and access to all Host Adapters and their connected CPUs. To logout as a user, press <L>... - Page 7 Make a Connection From the Command Mode menu, to make connection to any Host Adapter, press <Up arrow> or <Down arrow> to highlight and select the desired Host Adapter, press <Enter> to connect to it. - OR- use the mouse to highlight the desired Host Adapter to connect to and left-click on it to connect. Press <Esc>...
