- Page 1 NETWORK 1275 Danner Dr TECHNOLOGIES Aurora, OH 44202 INCORPORATED 2-Port Universal KVM Switch Installation and Operation Manual Tel:330-562-7070 Fax:330-562-1999 www.nti1.com NODEMUX Series ST-2U MAN042 Rev Date 4/15/2004...
-
Page 2: Warranty Information
A return authorization number is required for all repairs/returns. COPYRIGHT Copyright © 2004 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. -
Page 3: Table Of Contents
Figure 9- Connect SUN CPU to ST-2U... 6 Figure 10- Use a NTI VOPEX-IM9D with serial type mouse port ... 7 Figure 11- Connect audio signal and speakers to a ST-2U-A ... 7 Figure 12- Connect a touch-screen monitor to ST-2U-TS ... 8 Figure 13- Connect serial device cable from CPU to ST-2U-TS... -
Page 4: Introduction
120VAC or 240VAC at 50 or 60Hz-9VDC/0.5A AC Adapter Materials Not Supplied, BUT REQUIRED: NOTE: A VGA multi-scan monitor must be used with this product. Exception- If an ST-2U-13W3 with built-in SUN video port has been purchased, then a multi-scan SUN monitor can be used. -
Page 5: Features And Functions
NTI NODEMUX SERIES UNIVERSAL KVM SWITCH N e t w o r k T e c h n o l o g i e s I n c FEATURES AND FUNCTIONS 1. CPU Select Switch- push to manually toggle between CPUs 2. -
Page 6: Installation
Configure the ST-2U for the keyboard type being used as per Fig. 1 below (SUN, PS/2 or MAC). The dip-switches on the front panel must be configured for the platform of the keyboard / mouse that will be used to operate the ST-2U. This action must be completed prior to powering up the ST-2U. -
Page 7: Figure 3- Connect Sun Monitor To St-2U-13W3
• PS/2- Attach the 8-pin miniDIN male end of a VKTINT-1 to the ST-2U switch at the "USER" port. The keyboard will plug into the purple 6 pin miniDIN female connector with the keyboard symbol on it (see Fig. 4a), and the mouse will plug into the green 6 pin miniDIN female connector with the mouse symbol on it (see Fig. -
Page 8: Figure 6- Connect Sun Keyboard/Mouse To St-2U
For each CPU connect the appropriate NTI input device and video cables to the proper ports on the ST-2U switch using the methods detailed below. NOTE: Make sure the cables from a single CPU are connected to the ST-2U at a keyboard port and a video port with the same number. -
Page 9: Figure 8- Connect Mac Cpu To St-2U
MAC- Attach a MKTINT-xx-MM cable between the keyboard port of the CPU and a 8 pin miniDIN female "CPU x" port on the ST-2U switch. Using a 15DM-15HDF adapter, attach a VEXT-xx-MM cable between the video port on the CPU and a 15HD female "VIDEO x"... -
Page 10: Units With Audio Support (Optional)
NTI NODEMUX SERIES UNIVERSAL KVM SWITCH WARNING! If a serial mouse port is being used on a PC to connect a serial CPU to an ST-2U switch, do not use a generic 9D-to-6mD adapter to make connection to the PS/2 cable-- use a VOPEX-IM9D to convert the signal from the serial port to PS/2. -
Page 11: Units With Touch Screen Support (Optional)
Units with touch screen support (optional) 1. Connect the 15HD male connector from a VGA multi-scan monitor to the port labeled MONITOR on the rear of the NTI ST-2U- TS switch. If a touch-screen type monitor is being used, connect the 9D male serial connector from the touch-screen monitor to the port in the USER set labeled SERIAL on the rear of the NTI ST-2U-TS switch. -
Page 12: Power Up/Down
USING THE NTI ST-2U 2-PORT UNIVERSAL KVM SWITCH Control over the CPUs attached to the NTI ST-2U 2-Port Universal KVM switch is achieved through operation of the ST-2U 2-Port Universal KVM switch. Once the ST-2U switch is properly connected, the ST-2U switch will enable a connection to be made between the CPUs attached to its "CPU x"... -
Page 13: Scan Mode
CPU. Normal Mode When only one CPU LED on the ST-2U switch is illuminated the user is in Normal Mode, controlling the CPU to which the user is connected through the ST-2U switch. The illuminated CPU LED indicates which CPU the user is connected to. -
Page 14: Usb Cpu Support
The ST-2U-U should have all cables attached before powering up. If no cable is plugged into either of the 8 pin miniDIN CPU ports labeled CPU 1 or CPU 2 (see Fig. 15) on the ST-2U-U, then their respective USB ports labeled for CPU 1 USB and CPU 2 USB on the ST-2U-U will become the default active CPU port(s). -
Page 15: Rs232 Control
NTI NODEMUX SERIES UNIVERSAL KVM SWITCH PLEASE NOTE: It is necessary to configure a Sun CPU such that the Sleep Mode is not enabled. If a Sun CPU goes into sleep mode either automatically or manually, the user must reboot the Sun CPU in order to resume use of the Sun CPU. To disable the Sleep Mode, perform the following steps: Select "Power Manager"... -
Page 16: Dipswitches
NTI NODEMUX SERIES UNIVERSAL KVM SWITCH Dipswitches The dipswitches located next to the RS232 connection (Fig. 8) are used to configure the baud rate and address of the NODEMUX. The default baud rate is 9600. Use the charts below to change the baud rate and address as needed. BAUD RATE DIP SWITCH The baud rate can be... -
Page 17: Matrix Options
PS/2 workstations connected to the switch. The NTI ST-2U-TS includes serial cable connection ports in addition to the video and keyboard/mouse ports (see Fig. 18). The Serial ports may be used for the data communications (DATA I/O) from a VGA multi-scan monitor with touch-screen features if the monitor has touch-screen features. -
Page 18: Audio Support
Dual Video support enables CPUs with two video outputs to be connected to the NODEMUX switch and two user monitors to be connected to view both sets of video signals. Figure 20- Connections for video cables on the ST-2U-DV Both monitors must be of the type VGA multi-scan. -
Page 19: Keyboard-To-Cpu Translation
NTI NODEMUX SERIES UNIVERSAL KVM SWITCH KEYBOARD-TO-CPU TRANSLATION The NTI ST-2U Universal KVM switch enables the connection of otherwise incompatible peripheral computer components to each other. This is accomplished by performing keyboard-to-CPU translations automatically (i.e. connect a MAC keyboard and mouse to a PS/2 type CPU). -
Page 20: Troubleshooting
NTI NODEMUX SERIES UNIVERSAL KVM SWITCH TROUBLESHOOTING If the ST-2U 2-Port Universal KVM switch is not working properly, consider the suggestions below to see if a solution can be found. • Verify that all cables are securely connected. • Verify that the CPU is connected to a Keyboard port and Video port with the same CPU port number.
