Maintenance And Service
G
D
R
LASS
OOR
EMOVAL
Figure 8: Top bolts for glass door.
B
& B
URNER
LOWER
1. Turn the unit off and allow the unit to cool
completely.
2. Remove the fascia or louvers, open the door
(see M
AINTENANCE AND
R
), and remove the log set.
EMOVAL
3. Remove the log support tray by lifting the
back of the tray up and pull it out from under
the lip. Take care to not knock the pilot and
the side brick panels.
4. Remove the centre and top brick panels (see
S
I
ECONDARY
NSTALATION
P
).
ANEL
5. Turn gas supply off and remove gas
connection. Disconnect the wiring from the
side of the appliance.
6. Remove the three (3) T-20 screws just
above the burner top on the back firewall
(see Figure 10) and the two (2) screws on
each side below the burner top. Carefully
remove the complete gas and electrical tray assembly from the firebox, ensuring that no wires or gas
lines are damaged.
7. Remove the blower and housing from the gas tray assembly by removing the three (3) fastening screws
located on the back of the gas tray assembly. Pull the fan out from under the gas tray. Disconnect the
wiring from the fan temperature sensor and remove fan.
8. Hook up wires from the new blower to main wiring harness and fan temperature sensor. Install the
blower in the reverse order as described in Step 7.
6. Reinstall the completed gas tray into the firebox, being careful not to damage any wires or gas lines.
Properly secure the gas tray assembly in the firebox. Hook up gas lines and wiring harness. Perform a
gas leak check on all gas line with a soap and water solution or an approved method.
7. Return unit to original location if moved. Re-install the log support tray, the brick panels, the logset
(see S
I
ECONDARY
8. Check burner and blower assembly for proper operation.
Caution: Bleed lines before lighting and light pilot with door open.
10
QUALIFIED INSTALLERS ONLY
:
Open the door by removing the two (2)
/
'' bolts located at the top outside
5
16
corners of the glass frame (see Figure
8). Lift the bottom of the door up and
remove from unit (see Figure 9).
R
:
EMOVAL
S
- G
ERVICE
LASS
- R
T
EMOVING
HE
- L
S
NSTALATION
OG
ET AND
CAUTION GLASS MAY
SEPARATE FROM DOOR.
D
OOR
Burner Top with
Grate Attached
Gas & Electrical
Tray Complete
B
RICK
Log Support
Tray
Figure 10: Removing burner and gas tray.
E
I
MBER
NSTALLATION
Figure 9: Bottom hooks for
glass door.
), the door and the fascia or louvers.
Blower / Fan
