About this Quick Start Guide
Thank you for choosing First Alert for your security needs! This Quick Start Guide is designed to provide you with the basic
operation of your PRO-D1610 DVR. Please consult the complete User's Manual included on the CD disk for a detailed explanation
of all the features and functions of this DVR. We also encourage you to visit our website at www.brkelectronics.com to check for
the latest manuals (English and Spanish), firmware updates, downloads, other security camera products and announcements.
You'll find this product line under Products >> Security Cameras >> Wired Cameras.
Front Panel
Item
Function
Standby
1
IR Sensor
2
MENU/EXIT
3
LED Indicators
4
Channel Numbers
5
During playback,
6
press the following:
Navigation/OK/PTZ
(Select direction
7
arrow, then press OK
to start PTZ motion)
USB
8
4
7
Control
Description
Press to enter standby mode
IR receiver for the remote control
Press to open/close the main menu
Shows status of Link, 100M, Full, Alarm, Record, HDD.
Press buttons 1~9 to view the selected channel in full-screen. To display 2-digit chan-
nels press both buttons slowly. Pressing 0 returns screen to 16 camera display mode.
Increase reverse playback speed 2X, 4X, 8X
Press to freeze playback to one frame, then press again to advance frame-by-frame
Press to start playback
Press to slow playback speed by 1/2, 1/4, 1/8
Press to increase forward playback speed 2X, 4X, 8X
In menus, press to confirm selections; in PTZ mode, press to change the navigation
buttons to control the connected PTZ camera (not included)
Press to move cursor up; in PTZ mode, press to pan camera up
Press to move cursor down; in PTZ mode, press to pan camera down
Press to move cursor left; in PTZ mode, press to pan camera left
Press to move cursor right; in PTZ mode, press to pan camera right
Connect a USB flash drive to the left port for data backup and firmware upgrades.
Connect a USB mouse to the right port
product overview
6
5
Page 3
dvr controls
3
8
1
2
