Summary of Contents for Carrier Comfort Touch-n-Go
- Page 1 Programmable Owner's Manua_ turn to the experts_...
- Page 2 have Comfort Programmable thermostat. This unique device's state-of-the-art technology makes it easier than ever for you to keep your home comfortable. Designed to be as smart - and smart-looking - as any of the other electronics your home, your new thermostat offers programming options to fit your lifestyle - not anybody else's.
- Page 3 BUTFON IDENTIFICATION ........ON-SCREEN INDICATORS ........QUICK START Setting the time a nd d ay........... Setting the t emperatures for h eating and c ooling ......Changing the temperature ........Understanding Touch 'N'Go"feature ......PROGRAMMING THE T HERMOSTAT Programming the Touch 'N'Go feature ......Setting the home temperature ........
- Page 4 Turning off t he continuous backlighting ......Keypad lockout ..........Unlocking the keypad .......... Changing from programmable tononprogrammable ....Changing the number ofprogramming periods ......SPECIAL FEATURES Auto c hangeover ..........Smart Recovery ..........WHAT IF... The b attery icon i sdisplayed ........
- Page 5 © mode © hold © © d/h/m -set days period start time _hedufa...
- Page 6 Selects whether the fan operates continuously (on) or only when needed for heating or cooling (auto) RUN/HOLD Holds the currently selected temperature or runs the scheduled program MODE Selects whether thermostat heating, cooling, emergency heat (heat pump system only), auto (heat and cool as needed), or off Increases temperature...
- Page 7 ....j_,,, oF _ ..|o,-_ heatQ_ actual temp on C|O temporory ,,; , hold all days fanautostartt".QmOQAM weekdays a,,tl c, lm00 PM weekends...
- Page 8 1. Clock 2. Fan mode - on or auto 3. Selected heating set point; "on" indicates system is in heating mode 4. System is in auxiliary (supplemental) mode 5. Current temperature 6. Thermostat mode is either off or using emergency heat 7.
- Page 9 Setting the time and day must time before of the thermostat's programming features. 1. Open the door. display screen. The day of the week will flash on the dis- © 2. Press the d/h/m button. It's on the lower right, under play.
- Page 10 Setting the temperatures for heating and cooling Your thermostat is installed with pre-set heating and cooling temperature settings. You can use these or change them so your home is as warm or as cool as you'd like it to be. These steps will hold the temperature where you set it.
- Page 11 the mode 5. Press button located on the left side of the dis- play once. You will see the preset temperature setting cooling appear on the right side of the display. © 6. Press the up or down button. The word cool will flash.
- Page 12 Changing the temperature There are times when you want to change the temperature. Here's how. 1. Open the door. °l_le 2. Press the up or down buttons on the right side until you o_o reach the desired temperature setting. This creates a "tern- o porary...
- Page 13 Understanding Touch 'N' Go feature The unique Touch 'N' Go feature on your thermostat is a revolutionary tool that lets you use a simpler programming option - literally, touch go - to help you get the maximum comfort control from the entire comfort system.
- Page 14 Programming the Touch 'N' Go feature The Touch 'N' Go feature on your thermostat involves the home, away and sleep buttons immediately" under display'. They" are used programming options. One is more sophisticated than the other. simpler programming option requires either accept preset...
- Page 15 The m ore s ophisticated programming option works well with people who tend t o follow amore p redictable routine and who also w ant toget t he most from this thermostat's potential. For b oth p rogramming options, you must set-up your Touch 'N'Go heating and c ooling temperatures inorder touse t he thermostat's...
- Page 16 Use this blank grid to determine how warm or cool you want your home to be when you're home, away or asleep. You'll assign time periods to those temperatures later. TO __g Home Away Sleep...
- Page 17 Setting the home temperature 1. Open the door. 2. Press home button located under the display on the left. You will see a triangle icon (V) above the home but- ton. This icon will always tell you whether you're in the home, away or sleep...
- Page 18 Setting the away temperature 1. Press the away button located under the display in the cen- ter. You will see a triangle icon above the away but- o_----_o ton. 2. You will heating cooling temperatures that were set at the factory. To use these, just close the door.
- Page 19 Setting the sleep temperature 1. Press the sleep button located under the display in the center. You will see a triangle icon (y) above the sleep o_-------_o button. 2. You will see the heating and cooling temperatures that were o_o set at the factory.
- Page 20 7.Press the up or down button until you reach the desired ® temperature setting. 8. Press and hold the sleep button for about three seconds. The set temperature will flash, indicating that it saved your settings. 9. Close the door. Changing the temperature time periods After you have set your three Touch...
- Page 21 The t hermostat has p reset periods (see below), but you can c hange these tofityour lifestyle. 6:00 A M to8:00 A M 8:00 A M to5:00 P M 5:00 P M to10:00 PM 10:00 PM to6:00 AM What time blocks work for you? Write them in here and refer to this as you make the changes on the thermostat.
- Page 22 Here's how tochange the factory-set time p eriods, o_--_o 1.Open the door. 2.Press the days button at the bottom of the thermostat. © will see all days, weekdays and weekends flashing • o o o the display. You will be changing the time periods accord-...
- Page 23 6. You will see the hours in 6:00 flashing on the screen. Press the up or down button and stop on the desired time. 7. To change the minutes, press the start time button on the bottom of the screen again.
- Page 24 10. T ochange the minutes, press the start time button onthe bottom o fthe screen again. You w illsee t he minutes 8:00 flashing on the screen. Press the up or down button and stop on the desired time. 11. To change the start time for period 3 (P3), press...
- Page 25 17. I f you did not s elect all days when you started this process, repeat all the steps for your remaining time-frame choice - weekdays or weekends. 18. To confirm that the thermostat has accepted your changes, cycle through four time periods by pressing...
- Page 26 Assigning time periods to temperatures To get the most from your thermostat's programming features, you will want to take the remaining steps that will link your four schedule time periods (P1, P2, P3 and P4) to the heating and cooling temperatures you set with the Touch...
- Page 27 Complete this schedule according to daily routine it as you follow instructions below. Here's how to connect your four time periods with the three comfort ranges - home, away and sleep. 1. Open the door. 2. Press the days button at the bottom of the thermostat.
- Page 28 3. Select of these three options by pressing the up down button located to the right of the display. You may ® also make your selection by pressing days button again. Select all days if your weekday schedule is the same as your weekend schedule.
- Page 29 7.Press home, away or sleep. the period P3 will flash 8. Press button twice. on the display. 9. Press home, away or sleep. 10. Press the period button twice. P4 will flash on the display. 11. Press home, away or sleep. 12.
- Page 30 Using Touch 'N' Go buttons Once have set the temperatures and time periods that correspond with your three Touch 'N' Go comfort buttons (see Programming the Touch 'N' Go feature, page 13, and Assigning time periods to temperatures, page 26), you won't need to use your Touch Go buttons...
- Page 31 3. To return to the originally programmed lifestyle period, press the appropri- ate home, away or sleep button. The system will return to that time peri- temporary od and the words hold will disappear. 4. Close the door. To hold it at home, away or sleep There might be situations when you want...
- Page 32 4. To return to your original programming schedule, press the o_o 5. Close the door. hold/run button. The word holU will disappear, Using the thermostat to turn the heating and cooling system Here's how to use the thermostat to turn the heating and cooling system off.
- Page 33 Using the fan fan function helps distribute warmth or cooling throughout your home for a more even temperature in all spaces. The thermostat is automatically set so that the fan runs only during your heating and cooling cycles (auto mode). However, can adjust the settings so that the fan...
- Page 34 Using emergency heat (heat pump systems only) Emergency heat is useful when the automatic auxiliary heat system can't keep with demand. (Systems with heat pumps use "auxiliary heat" when it's too cold outside for the heat pump to heat the house without help.
- Page 35 Changing the batteries Your thermostat is probably powered by the HVAC equipment, but if it isn't, it's battery powered. can tell if it's battery powered by checking in Advanced Programming Options. (See page 37.) If there's no lighting until you touch a button, it's battery powered.
- Page 36 We recommend that you replace the batteries atthe one b ar l evel withtwoAAalkaline batteries. They're in theback o f the thermostat, so you'll have toremove itfrom the w all. Here's how. 1.Ix_cate the latch a t t he top ofthe thermostat. It's atthe cen- ter o fthe top rim.
- Page 37 6.Install new batteries by matching the "plus" and " minus" ends ofthe batter- ies with the "plus" and " minus" indicators you'll see o utside the two white battery shapes inthe space where the batteries sit. 7.Snap the batteries into place. 8.Put the thermostat back onthe wall b racket bylining u pthe two slots o n the bottom edge ofthe back ofthe thermostat...
- Page 38 Advanced programming display codes chart can customize several features of your thermostat. This chart shows which features you can change the codes associated with them. codes will shown on the display when you follow the instructions. Fahrenheit to Celsius F or C backlighting On or Of keypad...
- Page 39 Changing from Fahrenheit to Celsius Your thermostat is preset to display the temperature in degrees Fahrenheit. You can change this to Celsius. 1. Open the door. o_--------_o 2. Press and hold the home and sleep buttons under the dis- o_o play simultaneously for about three seconds.
- Page 40 Turning off the continuous backlighting If your thermostat is not powered by the equipment and is instead battery powered, the display will light up for a few seconds after you press any button. This backlighting. It will go dark: after a few seconds. If the thermostat is powered by electricity,...
- Page 41 5. Press the done button on the right. 6. Close the door.
- Page 42 Keypad lockout The keypad lockout feature lets you "lock" the thermostat so nobody can change temperature or make other changes by pressing buttons. Keypad lockout is not activated when the thermostat is installed. Here's how to activate 1. Open the door. °1_I°...
- Page 43 Unlocking the keypad Here's how to temporarily unlock the keypad. 1. Open the door. 2. Press and hold the up and down buttons on the right simultaneously about five seconds, o_--------_o 3. The padlock icon will disappear. This means the keypad is unlocked can be used.
- Page 44 Changing from programmable to nonprogrammable is possible convert your thermostat's operation from programmable nonprogrammable. This eliminates its advanced features. When switching to the nonprogrammable format, you lose the programming, hold, days of the week on the display, Smart Recovery features. Switching to nonprogrammable also means...
- Page 45 the mode 4. Press button on the left, P will flash. 5. Press the up button on the right to change it to nP for nonprogrammable 6. Press the done button on the right. 7. Close the door.
- Page 46 Changing the number of programming periods Your thermostat is preset with four time periods (P1, P2, P3, P4). You can change this to two. Here's how to change the number of periods in the day. 1. Open the door. 2. Press and hold the home and sleep buttons...
- Page 47 Auto Changeover The thermostat displays one of five modes: heat, cool, Em heat (heat pump version only), heat cool, and off. When the mode selection is for both heating and cooling, the thermostat is in auto changeover mode. This allows the system to switch from...
- Page 48 The battery icon is displayed The battery icon appears on the display only when the battery starts to lose power. Replace it when one-third of the icon is black. If you wait until the icon is just a silhouette with no black bars, the thermostat won't have...
- Page 49 There is a power outage If you lose electricity" and have batteries installed, the thermostat will continue display the status because it has a battery backup power source. This means that even though your heating and cooling system doesn't work, you will still be able to monitor your...
- Page 50 Auto changeover ........page 46 This feature automatically switches your system from heating to cooling - and from cooling to heating - whenever necessary when the thermostat is set in auto mode. Auxiliary heat (heat pump systems only) ....page 33 Most heat pump...
- Page 51 Emergency heat (heat pump systems only) .... page 33 manually the thermostat to use emergency heat it is the most expensive option. If it's using emergency heat, the display will show Em heat when you press the mode button. Hold ............ page 30 This function holds...
- Page 52 Temporary hold ........page 29 This function lets you temporarily maintain your temperature settings. The system will return to the scheduled settings during the next time period. Time period ........... page 19 thermostat features four time periods. These blocks of time linked temperatures set according...
- Page 54 OR REPAIR: Contact the installer or a Carrier dealer. You may find the installer's name on the equipment in your Owner's Packet. can also find a Carrier dealer online at www.carrie_:com For help, contact: Carrier Corporation, Consumer Relations, 4808, Syracuse, York...
- Page 55 The w arranty period is one (1) y ear on all s uch application LEGAL REMEDIES: The o wner must notify Company writing, certified registered letter to Carrier Corporation, Warranty Claims, Box 4808, Syracuse, York 13221, of any defect or complaint...
- Page 56 WARRANTY CONDITIONS: 1. To obtain the longer warranty periods as shown in the table under original owner, original purchaser, product must properly registered at www.carrie_:com within ninety (90) days of original installation. In jurisdictions where warranty terms conditioned on registration are prohibited by law, registration...
- Page 57 PROVINCES DO NOT A LLOW LIMITATIONS ON HOW LONG A N IMPLIED WARRANTY OR CONDITION LASTS. SO THE ABOVE APPLY YOU. EXPRESS WARRANTIES MADE IN THIS WARRANTY EXCLUSIVE ALTERED, ENLARGED, CHANGED DISTRIBUTOR, DEALER. OTHER PERSON. WHATSOEVER THIS WARRANTY DOES COVER: 1.
- Page 58 Copyright 2010 Carrier Corporation 73t0 W. Morris St, Indianapolis IN 46231 Printed in the U .S,A. Catalog No: OM-TCPHP-4CA Replaces: TCPHP Edition Date: 02/10 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
