by SIAL
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
INDIRECT FIRED
PORTABLE HEATER
If the information in this manual is not followed exactly, a fire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— Service must be performed by a qualified service agency.
This is an unvented portable heater. It uses air (oxygen) from the area in which it is used. Adequate
combustion and ventilation air must be provided. Refer to page 3.
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500
Model #
HS180ID
HS300ID
07/04 #50100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enerco HeatStar HS180ID
Summary of Contents for Enerco HeatStar HS180ID
- Page 1 This is an unvented portable heater. It uses air (oxygen) from the area in which it is used. Adequate combustion and ventilation air must be provided. Refer to page 3. ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500 OPERATING INSTRUCTIONS AND OWNER’S MANUAL...
- Page 2 • ONLY USE AN ORIGINAL H07RN-F POWER CABLE WITH WATERPROOF PLUG. • DO NOT TOUCH THE EXHAUST GAS OUTLET. DANGER OF BURNS! ENERCO GROUP, INC. |Indirect Fired Portable Heater WARNING: NOT FOR HOME OR RECREATIONAL VEHICLE USE WARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD.
-
Page 3: Specifications
• When the heater is used in a closed room, ensure a minimum volume of 28,300 ft³ for the HS180ID model and 53,000 ft³ for the HS300ID model and a continuous natural air circulation through windows and doors. For a good combustion, provide approximately 47 cfm air flow from outside. -
Page 4: Shut Down
To reset the thermostat: unplug the heater, open the inspection cover and push the reset button on the thermostat body. ENERCO GROUP, INC. |Indirect Fired Portable Heater Shut down. • Set switch to “OFF” to shut the flame off. The fan will go on rotating for about 1’45”... -
Page 5: Troubleshooting
Heater stops due to safety thermostat •The appliance has overheated •Faulty safety thermostat WIRING DIAGRAM ENERCO GROUP, INC. |Indirect Fired Portable Heater SOLUTION •Check main distribution board and power supply line •Check/have cable replaced by a qualified electrician •Check and replace if required •Set room thermostat on a higher temperature... - Page 6 Fuel Solenoid Valve Ignition Transformer Motor Warning Lamp Safety Thermostat Fuse Flame Sensor Reset Button Switch Room Thermostat (Optional) Heated Filter (Optional) ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 7 THIS PAGE INTENTIONALLY LEFT BLANK. ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual...
-
Page 8: Parts Ordering Information
If a part is damaged or missing, call our Technical Support Department at 800-251-0001. Address any Warranty Claims to the Service Department, Enerco Group, Inc., 4560 W. 160TH ST., Cleveland, Ohio 44135. Include your name, address and telephone number and include details concerning the claim.
