OPERATING INSTRUCTIONS AND OWNER'S MANUAL
MR. HEATER
MH80CV, MH200CV
CONVECTION
CONSTRUCTION HEATER
If the information in this manual is not followed exactly, a fire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appli-
ance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light appliance.
•
Extinguish any open flame.
•
Shut off gas to appliance.
— Service must be performed by a qualified service agency.
This is an unvented gas-fired portable heater. It uses air (oxygen) from the area in which it is used.
Adequate combustion and ventilation air must be provided. Refer to page 3.
READ INSTRUCTIONS CAREFULLY: Read and
follow all instructions. Place instructions in a
safe place for future reference. Do not allow
anyone who has not read these instructions to
assemble, light, adjust or operate the heater.
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500
HEATSTAR
HS80CV, HS200CV
04/04 Revision L2 #70486
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enerco HEATSTAR HS200CV
Summary of Contents for Enerco HEATSTAR HS200CV
- Page 1 This is an unvented gas-fired portable heater. It uses air (oxygen) from the area in which it is used. Adequate combustion and ventilation air must be provided. Refer to page 3. ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500 HEATSTAR...
-
Page 2: Table Of Contents
80CV - PARTS ... 8 200CV - PARTS ... 9 WARRANTY ... 12 INSTRUCTIONS FOR ORDERING PARTS ... 12 Enerco Group, Inc. |Convection Construction Heater WARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DIS-... -
Page 3: Operating Precautions
Opening Heater near floor Convection 80CV, 200CV ... 2 ft Enerco Group, Inc. | Convection Construction Heater SAFETY PRECAUTIONS Check the heater thoroughly for damage. DO NOT operate a damaged heater. DO NOT modify the heater or operate a heater which has been modified from its original condition. -
Page 4: Odor Fade Warning
Properly trained service people must repair any leaks, check for further leakages, and then relight the appliance for you. Enerco Group, Inc. |Convection Construction Heater ODOR FADING - NO ODOR DETECTED • Some people cannot smell well. Some people cannot smell the odor of the man-made chemical added to propane (LP) or natural gas. -
Page 5: Caution: Shell Extension Instructions
CAUTION: NEVER IGNITE AND / OR RUN THIS HEATER UNLESS THE SHELLS ARE FULLY EXTENDED AND LOCKED INTO POSITION. Enerco Group, Inc. | Convection Construction Heater STEP 2: LIFT OUTER SHELL STRAIGHT UP. CARE MUST BE TAKEN TO PROTECT HANDS DURING LIFT. -
Page 6: Operating Instructions
RESTART AFTER SAFETY SHUTDOWN Securely close valve at propane cylinder. Wait 5 minutes. Restart following "Start" procedure. Enerco Group, Inc. |Convection Construction Heater MAINTENANCE AND STORAGE The heater should be inspected before each use, and at least annually by a qualified person. -
Page 7: Size And Capacity Of Propane Cylinders Required
Move straight up to time of operation desired (left side of chart). Read the cylinder size required. All heaters should have: full cylinders good air circulation no frost on cylinders 80CV Enerco Group, Inc. | Convection Construction Heater 200CV Fuel Cylinder Capacity: 100# Operating Instructions and Owner’s Manual... -
Page 8: 80Cv - Parts
M6433 POL Excess Flow M6568 Fitting Adapter 1/4 FPTx1/4 MPT M8018 Fitting Adapter 1/8 FPT x 1/4 MPT 70486 Manual, Operating Instructions Enerco Group, Inc. |Convection Construction Heater (80CV ONLY) (200CV ONLY) REF. # ITEM # Description M6255 Regulator M8654... -
Page 9: 200Cv - Parts
Ftg., Elbor Female 1/4 FLRx1/8 FPT M6138 Ftg., Elbow Female 1/4 FPTx1/4 FLR 1 M8643 Thermocouple M6252 POL Excell Flow M6256 Regulator Enerco Group, Inc. | Convection Construction Heater (80CV ONLY) (200CV ONLY) REF. # ITEM # Description M8654 Valve, Ball M6473... -
Page 10: Parts Ordering Information
This Warranty gives you specific legal rights, and you may have other rights which vary from state to state. Enerco Group, Inc., reserves the right to make changes at any time, without notice or obligation, in colors, specifications, accessories, materials and models.
