OPERATING INSTRUCTIO NS AND OWNER'S MANUAL
READ INSTRUCTI O NS CAREFULLY:
and follow all instructions. Place instructions in
a safe place for future reference. Do not allow
anyone who has not read these instructions to
assemble, light, adjust or operate the heater.
NATURAL GAS/ LPG FIRED
DIRECT FIRED HEATER
If the information in this manual is not followed exactly, afire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— Service must be performed by a qualified service agency.
This is a vented portable heater. It uses air (oxygen) from the area in which it is used. Adequate
combustion air and ventilation must be provided. Refer to page 5.
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001
Read
HEATSTAR
BY ENERCO
HS4000 NG/LP
08/11
50401
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Enerco HEATSTAR HS4000 NG/LP
Summary of Contents for Enerco HEATSTAR HS4000 NG/LP
- Page 1 This is a vented portable heater. It uses air (oxygen) from the area in which it is used. Adequate combustion air and ventilation must be provided. Refer to page 5. 08/11 50401 ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001...
-
Page 2: Table Of Contents
BY QUA LIFIED PERSONNEL. PARTS LIST ................11-16 • ONLY USE AN ORIGINAL H07RN-F POWER CABLE WITH WAT ERPROOF PLUG. • DO NOT TOUCH THE EXHAUST GAS OUTLET. DANGER OF BURNS! ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 3: Warnings
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE INJURY OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. WARNING : RETAIN THIS INSTRUCTION FOR FUTURE REFERENCE ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 4: Specifications
56,,1 x 29,5 x 25,7 Heater Weight [lb] Dimensions, L x W x H [in] 42,3 x 21,9 x 29,45 57,7 x 24,4 x 32,6 Packaging Weight [lb] ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... - Page 5 MANIFOLD ASSEMBLY GE/N 250 GE/N 400 Fig. 2 GAS SELECTOR VALVE MAIN GAS VALVE MANIFOLD PRESSURE PORT (MANIFOLD) INLET PRESSURE PORT MANIFOLD PRESSURE REGULATOR SHUT OFF / FIRING VALVE ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual...
-
Page 6: Safety Devices
• The generator is regularly monitored during operation and must be arranged by the person in charge of installation. checked before being started up; • Don’t let animals or children near the heater. ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 7: Operation
MANUFACTURER’S AUTHORIZED REPRESENTATIVE, correct, the unit may stop in the reset mode. IN ACCORDANCE WITH THE REQUIREMENTS OF THE MANUGFACTURER, PROVINCIAL OR TERRITORIAL AUTHORITIES HAVING JURISDICTION HEATING MODE ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 8: Maintenance
(4) can cause the flame to work with risk to the health of exposed persons (because of formation of carbon monoxide, CO) and constituting a danger for the environment. ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 9: Troubleshooting
• Foreign bodies on fan blades • Remove foreign bodies • Fan noise or vibrations • Little air circulation • Eliminate and obstacles to proper air flow ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... -
Page 10: Wiring Diagrams
CONTROL LAMP IONIZATION ELECTRODE GAS TRAIN FUSE COOLING MOTOR POVERHEAT THEMOSTAT VENTILATION MODE SWITCH PRESSURE SWITCH 20 Pa POST-VENTILATION RELAY ROOM THERMOSTAT PLUG TRANSFORMER H.T. CAPACITOR HEATING SWITCH ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual... - Page 11 ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 12 ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 13 ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 14 This Warranty gives you speci c legal rights, and you may have other rights which vary from state to state. Enerco Group, Inc. reserves the right to make changes at any time, without notice or obligation, in colors, speci cations, accessories, materials and models.
