1.2
Specifications
Platform
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- All Solid Capacitor design (AD2700B-ITX)
- Solid Capacitor for CPU power (AD2500B-ITX)
CPU
- Intel
(AD2700B-ITX)
- Intel
(AD2500B-ITX)
- Supports Hyper-Threading Technology (AD2700B-ITX)
(see CAUTION 1)
Chipset
- Southbridge: Intel
Memory
- 2 x DDR3 SO-DIMM slots
- Supports DDR3 1066/800 non-ECC, un-buffered
memory
- Max. capacity of system memory: 4GB (see CAUTION 2)
Expansion Slot
- 1 x PCI slot
Graphics
- Intel
- DirectX 9.0, Pixel Shader 3.0
- Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
Audio
- 5.1 CH HD Audio (VIA
LAN (AD2700B-ITX) - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Effi cient Ethernet 802.3az
- Supports PXE
LAN (AD2500B-ITX) - Realtek PCIE x1 LAN RTL8105E
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
- Supports PXE
Rear Panel I/O
I/O Panel
(AD2700B-ITX)
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Parallel Port (ECP/EPP Support)
- 1 x Serial Port: COM1
- 1 x VGA Port
- 2 x Ready-to-Use USB 2.0 Ports
- 2 x Ready-to-Use USB 3.0 Ports
ASRock AD2700B-ITX / AD2500B-ITX Motherboard
®
TM
Dual-Core Atom
Processor D2700 (2.13 GHz)
®
TM
Dual-Core Atom
Processor D2500 (1.86 GHz)
®
NM10 Express
®
PowerVR SGX545
®
VT1705 Audio Codec)
7
