2.4 Expansion Slot (PCI Slot)
There is 1 PCI slot on this motherboard.
PCI slot:
The PCI slot is used to install expansion card that has the 32-bit PCI
interface.
Installing an expansion card
Step 1.
Before installing the expansion card, please make sure that the power
supply is switched off or the power cord is unplugged. Please read the
documentation of the expansion card and make necessary hardware
settings for the card before you start the installation.
Step 2.
Remove the system unit cover (if your motherboard is already installed
in a chassis).
Step 3.
Remove the bracket facing the slot that you intend to use. Keep the
screws for later use.
Step 4.
Align the card connector with the slot and press fi rmly until the card is
completely seated on the slot.
Step 5.
Fasten the card to the chassis with screws.
Step 6.
Replace the system cover.
14
ASRock AD2700B-ITX / AD2500B-ITX Motherboard
