2 User’s Guide TABLE OF CONTENTS Quick Setup....................3~5 Product Features...................6 Warnings and Cautions.................8 Symbol Explanations...................11 EU Declaration of Conformity for Medical Applications......12 Prepare for Unpack..................12 Screen Position Adjustment...............13 Safety Precaution..................14 Cleaning Your Monitor.................14 Preset Modes....................15 Power Management Function..............16 DDC......................17 Installation.....................17 Display for Video and Image Back............18 Connecting with Video Equipment............18 User Controls....................19...
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 3 Quick Setup (IBM/IBM Compatible under Windows 95/98/ME/2000) Please Read Carefully When Setting Up Your New Monitor Monitor Screen Adjustment and Resolution Setting Procedure for IBM/IBM Compatible Computers with Windows based OS system. Before adjusting the monitor, all the necessary drivers should be installed to your System and resolution has to be set to manufacturer’s recommended preset of 1280 x 1024 @ 60Hz, 70Hz, 72Hz or 75 Hz.
Page 4
4 User’s Guide Quick Setup (IBM/IBM Compatible under Windows NT 4.0) Please Read Carefully When Setting Up Your New Monitor Monitor Screen Adjustment and Resolution Setting Procedure for IBM/IBM Compatible Computers with Windows based OS system. Before adjusting the monitor, all the necessary drivers should be installed to your System and resolution has to be set to manufacture’s recommended preset of 1280 x 1024 @ 60Hz, 70Hz, 72Hz or 75Hz.
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 5 Quick Setup (Macintosh) Please Read Carefully When Setting Up Your New Monitor 1. Set your Macintosh Adapter on pages 23 and 24. 2. Push the “APPLE” icon on the upper left corn and execute Control Panel-> Monitors&Sound. Select “Thousands” for the Color Depth, Select “1280X1024, 60Hz, 70Hz, 72Hz or 75Hz”...
6 User’s Guide INTRODUCTION Congratulations on your purchasing of the AMM170TK2/AMM17TK2/AMM18TK2/ AMM19TK2/AMM19TK2(HB) high performance TFT LCD monitor. Product Description and Intended Use The AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) Monitor is an intelligent, microprocessor-based TFT-LCD monitor intended for use in medical applica- tions. It has an ergonomically designed display and is compatible with most analog RGB (Red, Green, Blue) display standards.
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 7 Product Description Please check the following items are present when you unpack the box, and save the packing materials in case you will need to ship or transport the monitor in future. • AMM170TK2, AMM17TK2, AMM18TK2, AMM19TK2 or AMM19TK2/HB LCD Monitor and two video cable (1) VGA HDDB15 cable (1) DVI-D cable •...
8 User’s Guide Warnings and Cautions Please read this manual and follow its instructions carefully. The words warning, caution, and note carry special meanings and should be carefully reviewed: Warranty is void if any of these warnings are disregarded. ADVAN Int’l Corp accepts full responsibility for the effects on safety, reliability, and performance of the equipment only if: •...
Page 9
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 9 Warnings 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked by qualified personnel before operating it any further.
Page 10
10 User’s Guide Cautions 1. The AC Adapter must be plugged into a Grounded power outlet. 2. Use only the proprietary AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/ AMM19TK2(HB) power supply for the AMM170TK2/AMM17TK2/AMM18TK2/ AMM19TK2/AMM19TK2(HB) monitor. Make a proper connection by ensuring that the shrink tubing completely secures the connection between the DC power cord and the extension cord.
12 User’s Guide EU Declaration of Conformity for Medical Applications A Declaration of Conformity has been filed for this product. A sample of this document may be found in the addendum which accompanied this manual. For a copy of the Declaration of Conformity document, please contact ADVAN Int’l Corp.
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 13 SCREEN POSITION ADJUSTMENT In order to optimize the best viewing position, you can adjust the tilt of the monitor by using both of your hands to hold the edges of the monitor as shown in the figure below. The moni- tor can be adjusted to 28 degrees up as indicated by arrow below.
14 User’s Guide SAFETY PRECAUTION • Avoid placing the monitor, or any other heavy object, on the power cord to prevent fire or electrical shock from damage to the power cord. • Do not expose the monitor to rain, excessive moisture, or dust to avoid fire or shock hazard. •...
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 15 PRESET MODES To reduce the need for adjustment for different modes, the monitor has default setting modes that are most commonly used as given in the table below. If any of these display modes are detected, the monitor automatically adjusts the picture size and centering. When none of the mode is matched, the user can store their preferred modes in the user modes.
16 User’s Guide POWER MANAGEMENT FUNCTION The monitor is equipped with the power management function which automatically reduce the power consumption when not in use in three power level modes. • Stand-by Mode The monitor goes into stand-by mode when the horizontal sync signal is off for about 10 seconds.
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 17 To make your installation easier, the monitor is able to Plug and Play with your system if your system also supports DDC protocol. The DDC (Display Data Channel) is a communication protocol through which the monitor automatically informs the host system about its capabilities, for example, supported resolutions and corresponding timing.
18 User’s Guide Display for Video and Image Playback Explains how to use our AMM17TK, AMM18TK, AMM19TK and AMM19TK/HB to play VCR, view television, video game, or digital camera images. It also show you how to connect video and other types of video equipment to the display. Connecting with Video Equipment You can connect many types of video equipment to the display.
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 19 USER CONTROLS Front Panel Controls 1. Power LED: Lights up to indicate the power is turned ON. 2. Power Switch: To turn ON or OFF the power. 3. Up: To enter OSD menu then can use as moving forward in the OSD menu. 4.
20 User’s Guide OSD Scren Basic Section (VGA) For OSD display, push “Up”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between Push “Up” or “Down” button to select between “Brightness” or “Contrast” then push “Select” “Frequency”...
Page 21
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 21 OSD Scren Basic Section (VGA) For OSD display, push “Up”. For selecting Icon, push “Up” or “Down” Push the select button to execute the Zoom function Push “Up” or “Down” button to select between “Analog RGB”, “Digital RGB”, “Composite Video” or Push the select button “Super Video”...
22 User’s Guide OSD Scren Basic Section (DVI) For OSD display, push “Up”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between Push “Up” or “Down” button to select between “OSD Hor. Pos.”, “OSD Ver. Pos.”, “OSD Background”, or “Brightness”...
Page 23
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 23 OSD Scren Basic Section (DVI) For OSD display, push “Up”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between “Analog RGB”, “Digital RGB”, “Composite Video” or Push the select button “Super Video” Use “Left”...
24 User’s Guide OSD Scren Basic Section (C-Video or S-Video) For OSD display, push “Up”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between Push “Select” button then “Up” or “Down” “Brightness” or “Contrast” then push “Select” Push “Left”...
Page 25
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 25 OSD Scren Basic Section (C-Video or S-Video) For OSD display, push “Up”. For selecting Icon, push “Up” or “Down” Push the select button Push the select button Use “Left” or “Right” button to adjust Use “Left” or “Right” button to adjust Push the select button to execute Recall Push the select button Use “Left”...
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 29 TROUBLESHOOTING Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. • • • • • • • l l i , t f • •...
30 User’s Guide SPECIFICATION l l i ° ° > & " " ° ° ° ° ° ° * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 31 SPECIFICATION l l i ° ° > & " " ° ° ° ° ° ° * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
Page 32
32 User’s Guide SPECIFICATION l l i t l i ° ° > & " " ° ° ° ° ° ° * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
Page 33
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 33 SPECIFICATION l l i ° ° > & " " ° ° ° ° ° ° * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
Page 34
34 User’s Guide SPECIFICATION l l i ° ° > & " " ° ° ° ° ° ° * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 35 51LJ Medical Equipment E215822 This monitor is intended for use in Health Care Facilities model AMM170TK2/ AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide. No user serviceable parts inside, ask qualified personnel when accessing inside.
40 User’s Guide Connectors DC Input Connector Jack Power Input The SCD-014-1-A (SHIUA CHYUAN) or equivalent. i r c i t p Video Input 15 pin D-subminiature connector. The vedor P/N is DHSB-15 FRF7(LEOCO) or equivalent. 24 pin DVI-D connector. DDWG or equivalent connector.
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 41 Description of Warranty Advan warrants that the goods the goods sold hereunder will be free of defects in materials and workmanship, and such goods will substantially conform to the specifications furnished by Advan, and to any drawings or specifications furnished to Advan by the Buyer if approved by Advan.
Page 42
42 User’s Guide ADVAN DISCLAIMS ALL OTHER WARRANTIES EXPRESS OR IMPLIED INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, EXCEPT TO THE EXTENT THAT ANY WARRAN- TIES IMPLIED BY LAW CANNOT BE VALIDLY WAIVED. No oral or written information or advice given by ADVAN, its authorized service center, distributors, dealers, agents or employees, shall create another warranty or modify this warranty.
AMM170TK2/AMM17TK2/AMM18TK2/AMM19TK2/AMM19TK2(HB) 43 Tounchscreen User's Manual (AMM170TK2-TE/AMM17TK2-TE/ AMM18TK2-TE/AMM19TK2-TE/AMM19TK2(HB)-TE or AMM170TK2-TEW/AMM17TK2-TEW/AMM18TK-TEW/AMM19TK2- TEW/AMM19TK2(HB)-TEW) Quick Start 1.Connect Power Code and VGA Cable of LCD Monitor. 2.Connect Touchscreen DB9 male RS-232 cable. 3.Turn the LCD display Power ON. 4.Adjust the tilt of LCD Monitor. 5.Adjust the Picture of LCD Monitor. 6.Install driver software of Touchscreen (See "Driver software"...
Page 44
10. Click the start button, then click control panel. 11. Double-click touchscreen control panel. 12. Click the calibrate button and touch each of the three targets as they appear on the screen. Contacting ELO www.elotouch.com ELO Touchsystems INC. 6500 Kaiser Drive Fremont, CA 94554 USA...
