- Page 1 AUTO-SCANNING WITH DIGITAL CONTROL LCD COLOR MEDICAL MONITOR AMM15TK2/AMM15TK2-TE/AMM15TK2-TEW Operation Manual For future reference, record the serial number of your display monitor in the space below: SERIAL number The serial number is located on the back of the monitor...
- Page 2 Equipment although the failure does not inflict the bodily harm to the patients. ADAVN INT’L CORP.2005 “ELO” is a Registered trademark of Elo TouchSystems, Inc., All other trademarks are the property of their reference owners. This document is subject to change without notice.
-
Page 3: Table Of Contents
Power Management System…………………………………….. 15 User Controls………………………………………………………. 16 Standard OSD Operation…………………………………………. 16 OSD Function Description (Analog)……………………………. 17 OSD Function Description (C or S Video )…….………………. 18 Specification Of AMM15TK2..…………………………………….. 19 Supported Modes…………………………………………………... 20 Connectors…………………………………………………………... 21 Troubleshooting…………………………………………………….. 22 Electromagnetic Compatibility…………………………………… 24~27 Description of Warranty……………………………………………. 28~29... -
Page 4: Warnings And Cautions
Federal law (United States of America) restricts this device to use by, or on order of a physician. The ADVAN Int’l Corp AMM15TK2 Series Monitor has been tested under UL 60601-1 standard and UL listed for Medical application. ADAVN Int’l Corp reserves the right to make improvements in the product(s) described herein. -
Page 5: Warnings
Warnings 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked by qualified personnel before operating it any further. -
Page 6: Cautions
Cautions 1. The AC Adapter must be plugged into a Grounded power outlet. 2. Use only the proprietary AMM15TK2 power supply for the AMM15TK2 monitor. Make a proper connection by ensuring that the shrink tubing completely secures the connection between the DC power cord and the extension cord. -
Page 7: Product Description And Intended Use
RGB (Red, Green, Blue) display standards. Advan AMM15TK2 Series Medical Monitor consists of a low-profile molded plastic monitor head, video and a power supply. Options include a Super sonic Acoustic Wave (AMM15TK2- TEW) or Resistive (AMM15TK2-TE) touchscreen with interface cable. The display shows 262,144 colors with a pixel matrix of 1024 columns by 768rows. -
Page 8: Functional Description
Functional Description and Product Features • Display Type Color Active Matrix LCD • Control Buttons: -OSD menu display: Menu Button -Adjustment increase -Power on/off -Auto adjust & exit OSD menu: Auto Button • Adjust brightness/contrast directly with the adjustment increase/decrease buttons. •... -
Page 9: Cleaning Instructions
Cleaning Instructions Advan AMM15TK2 Series Monitors will continue to operate normally while being cleaned in a fashion normal for a hospital environment. This includes cleaning with a damp (wrung out), mild soapy cloth. Protection from various chemicals used for cleaning. -
Page 10: Symbol Explanations
Symbol Explanations Indicates proof of conformity to applicable European Economic Community Council directives and to harmonized standards published in the official journal of the European Communities Tested and certified by UL to UL60601-1. If this mark appears with the indicators "C" and "US" the product is certified for both the U.S and Canadian markets, to the applicable U.S and Canadian standards. -
Page 11: Regulatory Compliance
A Declaration of Conformity has been filed for this product. A sample of this document may be found in the addendum which accompanied this manual. For a copy of the Declaration of Conformity document, please contact ADVAN Int’l Corp. and request for AMM15TK2 DOC. Prepare for Unpack Before you unpack your monitor, prepare a suitable workspace. - Page 12 Please check if the following items are present when you unpack the box, and save the packing materials in case you will need to ship or transport the monitor in future. ·AMM15TK2 Series Medical Monitor, VGA cable, S-Video cable, BNC cable and BNC to RCA adapter.
-
Page 13: Ddc
To make your installation easier, the monitor is able to Plug and Play with your system if your system also supports DDC protocol. The DDC(Display Data Channel)is a communication protocol through which the monitor automatically informs the host system about its capabilities, for example, supported resolution and corresponding timing. -
Page 14: Screen Position Adjustment
Screen Position Adjustment (with optional stand) In order to optimize the best viewing position, you can adjust the tilt of the monitor by using both of your hands to hold the edges of the monitor as shown in the figure below. The monitor can be adjusted up to 30 degrees as indicated by arrow below. -
Page 15: Power Management Function
1 second Off. The screen is displayed after the vertical and horizontal sync signals are restored. Power Management System The AMM15TK2 Series Medical Monitor complies with the VESA DPMS power management proposal. The VESA DPMS proposal provides four phases of power-saving modes by detecting the horizontal sync signal as shown in the table blow. -
Page 16: User Controls
User Controls Front Panel Controls 1. Power LED : Lights up to indicate the power is turned ON. 2. Power Switch : To turn ON or OFF the power. 3. + : To increase the value of the parameter in the OSD you have selected for adjustment. -
Page 17: Osd Function Description (Analog)
OSD Function Description Under Analog RGB Display Item Function Brightness To increase or decrease the brightness. Contrast To increase or decrease the contrast. Frequency To adjust frequency (dot clock). Phase To adjust phase (clock-phase). Vertical. To move the screen upward or downward Horizontal To move the screen left or right. -
Page 18: Osd Function Description (C Or S Video )
Under Composite or Super Video Display Item Function To increase or decrease the hue level. Saturation To increase or decrease the saturation level. Brightness To increase or decrease the brightness. Contrast To increase or decrease the contrast. Frequency To adjust frequency (dot clock). Phase To adjust phase (clock-phase). -
Page 19: Specification Of Amm15Tk2
Optional Module * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model AMM15TK2-TEW and Resistive Touchscreen model AMM15TK2-TE 15" Color TFT Panel Active Matrix 1024 ×768 @ 75Hz Max. -
Page 20: Supported Modes
Supported Modes Mode Resolution(H 1024 1024 1024 1024 × H. Freq.(KHz) × 31.5 × 31.5 × 31.5 × 35.0 × 37.9 × 37.5 × 35.1 × 37.9 × 48.1 × 46.9 × 49.7 × 48.8 × 48.4 × 56.5 × V. -
Page 21: Connectors
Connectors DC Input Connector Jack Power Input The SCD-014-1-A (SHIUA CHYUAN)or equivalent. Pin Description 1 +12V DC Video Input 15 pin D-subminiature connector. The vendor P/N is DHSB-15 FRF7(LEOCO) or equivalent. Description Red Video Green Video Blue Video Logic Ground Red Video Ground Green Video Ground Blue Video Ground... -
Page 22: Troubleshooting
Troubleshooting Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. Problem Current Status LED ON Picture LED OFF LED Blinking · Unstable Picture Abnormal Picture Display is missing, center shift, or too small or too large in display size... - Page 23 This monitor is intended for use in Health Care Facilities model AMM15TK2 Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide. No user serviceable parts inside, ask qualified personnel when accessing inside.
- Page 25 25 25...
- Page 26 26 26...
- Page 27 27 27...
-
Page 28: Description Of Warranty
Description of Warranty Advan warrants that the goods the goods sold hereunder will be free of defects in materials and workmanship, and such goods will substantially conform to the specifications furnished by Advan, and to any drawings or specifications furnished to Advan by the Buyer if approved by Advan. - Page 29 ADVAN DISCLAIMS ALL OTHER WARRANTIES EXPRESS OR IMPLIED INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FI TNESS FOR PARTICULAR PURPOSE, EXCEPT TO THE EXTENT THAT ANY WARRAN TIES IMPLIED BY LAW CANNOT BE VALIDLY WAIVED. No oral or written information or advice given by ADVAN, its authorized service center, distrib utors, dealers, agents or employees, shall create another warranty or modify this warranty.
-
Page 30: Tounchscreen User's Manual
Tounchscreen User’s Manual (AMM15TK2-TE or AMM15TK2-TEW) Quick Start 1.Connect Power Code and VGA Cable of LCD Monitor. 2.Connect Touchscreen DB9 male RS-232 cable. 3.Turn the LCD display Power ON. 4.Adjust the tilt of LCD Monitor. 5.Adjust the Picture of LCD Monitor. - Page 31 10. Click the start button, then click control panel. 11. Double-click touchscreen control panel. 12. Click the calibrate button and touch each of the three targets as they appear on the screen. Contacting ELO www.elotouch.com ELO Touchsystems INC. 6500 Kaiser Drive Fremont, CA 94554 USA...
- Page 32 ADVAN INTERNATIONAL CORPORATION 47456 Fremont Blvd. Fremont,CA 94538 Tel : 510-490-1005 Fax : 510-490-1151 Web Page : http://www.advancorp.com...
