Elo TouchSystems AMM170TK Operation User's Manual

Hide thumbs Also See for AMM170TK:

Advertisement

Quick Links

All manuals and user guides at all-guides.com
AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 1
back of the monitor
The title "WARN IN G" is used to inform the users of
possible causes that could inflict the injury, death, or
property damage to the patients.
The title "C AUTIO N " is used to inform the users of
possible causes that could inflict the patients although
it might not severe enough to cause deaths.
The title "N O TE" is used to inform the users of items
tha t a re o f imp o rta nc e in te rms o f ins ta lla tio n,
operation, or maintenance of the Equipment although
the failure does not inflict the bodily harm to the
patients.
ADAVN INT’L CORP.2003
Revision Control
Date
Rev. 4 112003
WARN IN G
C AUTIO N
N O TE
Description
Document number

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMM170TK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elo TouchSystems AMM170TK

  • Page 1 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 1 back of the monitor WARN IN G The title "WARN IN G" is used to inform the users of possible causes that could inflict the injury, death, or property damage to the patients.
  • Page 2 All manuals and user guides at all-guides.com 2 User’s Guide TABLE OF CONTENTS Quick Setup................... 3~5 Product Features………………………………………………... 6 Unpacking ……………………………………………………..7 Symbol Explanations……………………………………………. 8 Regulatory Compliance……………………………………….… 8 EU Declaration of Conformity for Medical Applications……..9 Screen Position Adjustment……………………………………... 10 Cleaning lnstructions………………………………………….….
  • Page 3 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 3 Quick Setup (IBM/IBM Compatible under Windows 95/98/ME/2000) Please Read Carefully When Setting Up Your New Monitor SELECT UP Information To change the resolution to its factory recommended preset. Properties Display Properties...
  • Page 4 All manuals and user guides at all-guides.com 4 User’s Guide Quick Setup (IBM/IBM Compatible under Windows NT 4.0) Please Read Carefully When Setting Up Your New Monitor SELECT UP Information To change the resolution to its factory recommended preset. Properties Display Properties Setting Refresh Frequency...
  • Page 5 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 5 Quick Setup (Macintosh) Please Read Carefully When Setting Up Your New Monitor APPLE Thousands “1280X1024, 60Hz, 70Hz, 72Hz or 75Hz” Screen Adjustment Procedure AUTO...
  • Page 6 All manuals and user guides at all-guides.com 6 User’s Guide INTRODUCTION FEATURES • Advanced Viewing Solution (AVS) • Advanced Timing Setup (ATS) • Advanced Mounting Solution (AMS) • • • • • • •...
  • Page 7 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 7 UNPACKING • AUTO SELECT • • or MW116 • • • *Some Touchscreen Model Not Available...
  • Page 8: Symbol Explanations

    All manuals and user guides at all-guides.com 8 User’s Guide Symbol Explanations This monitor is intended for use in Health Care Facilities. Regulatory Compliance...
  • Page 9: Eu Declaration Of Conformity For Medical Applications

    All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 9 EU Declaration of Conformity for Medical Applications A Declaration of Conformity has been filed for this product. A sample of this document may be found in the addendum which accompanied this manual. For a copy of the Declaration of Conformity document, please contact ADVAN Int’l...
  • Page 10: Screen Position Adjustment

    All manuals and user guides at all-guides.com 10 User’s Guide SCREEN POSITION ADJUSTMENT...
  • Page 11: Cleaning Your Monitor

    All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 11 SAFETY PRECAUTION • • • • • • CLEANING YOUR MONITOR...
  • Page 12: Preset Modes

    All manuals and user guides at all-guides.com 12 User’s Guide PRESET MODES M ode R e s olution (H x V) H. Fre q. (KHz) V. Fre q. (Hz) 640 x 350 31.5 640 x 350 37.9 640 x 400 31.5 640 x 400 37.9...
  • Page 13: Power Management Function

    All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 13 POWER MANAGEMENT FUNCTION • Stand-by Mode • Suspend Mode • Off Mode Power Management System M o de D C Inp ut P o we r A C Inp ut po we r...
  • Page 14: Installation

    All manuals and user guides at all-guides.com 14 User’s Guide INSTALLATION Steps...
  • Page 15: Display For Video And Image Playback

    All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 15 Display for Video and Image Playback Connecting with Video Equipment Steps Connecting to a Television Signal Video and Sound...
  • Page 16: User Controls

    All manuals and user guides at all-guides.com 16 User’s Guide USER CONTROLS Front Panel Controls 1. Power LED: Lights up to indicate the power is turned ON. 2. Power Switch: To turn ON or OFF the power. 3. +: To increase the value of the parameter in the OSD you have selected for adjustment. To increase the brightness directly when OSD menu is not activated.
  • Page 17 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 17 OSD Scren Basic Section (VGA) For OSD display, push “Menu”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between Push “Up” or “Down” button to select between “Brightness”...
  • Page 18 All manuals and user guides at all-guides.com 18 User’s Guide OSD Scren Basic Section (VGA) For OSD display, push “Menu”. For selecting Icon, push “Up” or “Down” Push the select button Use “Left” or “Right” button to adjust Push “Up” or “Down” button to select between “Analog RGB”, “Digital RGB”, “Composite Video”...
  • Page 19 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 19 OSD Scren Basic Section (DVI) For OSD display, push “Menu”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between Push “Up” or “Down” button to select between “OSD Hor.
  • Page 20 All manuals and user guides at all-guides.com 20 User’s Guide OSD Scren Basic Section (DVI) For OSD display, push “Menu”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between “Analog RGB”, “Digital RGB”, “Composite Video” or Push the select button “Super Video”...
  • Page 21 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 21 OSD Scren Basic Section (C-Video or S-Video) For OSD display, push “Menu”. For selecting Icon, push “Up” or “Down” Push “Up” or “Down” button to select between “Brightness” or “Contrast” then push “Select”...
  • Page 22 All manuals and user guides at all-guides.com 22 User’s Guide OSD Scren Basic Section (C-Video or S-Video) For OSD display, push “Menu”. For selecting Icon, push “Up” or “Down” Push the select button Push the select button Use “Left” or “Right” button to adjust Use “Left”...
  • Page 23 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 23 OSD Function Description (Under Analog Display)
  • Page 24 All manuals and user guides at all-guides.com 24 User’s Guide OSD Function Description (Under Digital Display) Ite m Function D e s cription Brightness To increase or decrease the brightness. C ontrast To increase or decrease the contrast. Horizontal To move the screen left or right. Vertical To move the screen upward or d ownward.
  • Page 25: Osd Function Description (Under C-Video Or S-Video Display)

    All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 25 OSD Function Description (Under C-Video or S-Video Display) Ite m Func tio n D e s c riptio n H ue To inc re a se o r d e c re a se the hue le ve l.
  • Page 26: Troubleshooting

    All manuals and user guides at all-guides.com 26 User’s Guide TROUBLESHOOTING • • • • • • • • •...
  • Page 27: Specification

    All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 27 SPECIFICATION * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
  • Page 28 All manuals and user guides at all-guides.com 28 User’s Guide SPECIFICATION * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
  • Page 29 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 29 SPECIFICATION * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
  • Page 30 All manuals and user guides at all-guides.com 30 User’s Guide SPECIFICATION * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
  • Page 31 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 31 SPECIFICATION * All contents are subject to change without notice. * Touch Screen Model doesn’t include the Video-in (C-Video, S-Video) function. * Surface Wave Touchscreen model -TEW and Resistive Touchscreen model -TE...
  • Page 32 All manuals and user guides at all-guides.com 32 User’s Guide Connectors Pin Description 1 +12V DC 2 GND Video Input D e s c r i p t i o n P i n D e s c r i p t i o n P i n R e d V id e o G r e e n V id e o...
  • Page 33: Description Of Warranty

    All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 33 Description of Warranty Commencement and Duration of Warranty Place of Repair or Replacement Limitation of Warranty *Touch Screen:...
  • Page 34: Technical Assistance

    All manuals and user guides at all-guides.com 34 User’s Guide Installation Technical Assistance Service If a service is required please return the product for service using the original shipping container with the RMA number included in package on the outside of the box. In order to protect ADVAN employees form potential health hazards, ADVAN requires that the RMA product be disinfected before returning to ADVAN for service.
  • Page 35 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 35 Tounchscreen User's Manual (AMM17TK-TE/AMM18TK-TE/ AMM19TE or AMM17TK-TEW/AMM18TK-TEW/AMM19TK-TEW) Quick Start Introduction The ELO IntelliTouch Touchscreen system consists of a touchscreen and an electronic touchscreen controller. The touchscreen may be a flat, spherical, or cylindrical and is installed over the face of the LCD.
  • Page 36: Touchmonitor Installation

    10. Click the start button, then click control panel. 11. Double-click touchscreen control panel. 12. Click the calibrate button and touch each of the three targets as they appear on the screen. Contacting ELO www.elotouch.com ELO Touchsystems INC. 6500 Kaiser Drive Fremont, CA 94554 USA...
  • Page 37 All manuals and user guides at all-guides.com AMM170TK/AMM17TK/AMM18TK/AMM19TK/AMM19TK(HB) 37...
