EARLEX SPRAYSTATION 6900
®
OPERATING INSTRUCTION MANUAL
Thank you for purchasing the Professional Earlex low pressure paint system.
This highly versatile (high volume of air, low pressure painting) system can be
used for a wide variey of applications.
BEFORE USE - PLEASE READ THE MANUAL AND SAFETY INSTRUCTIONS.
Please retain for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EARLEX SPRAYSTATION 6900 and is the answer not in the manual?

Questions and answers

Related Manuals for Earlex EARLEX SPRAYSTATION 6900

Summary of Contents for Earlex EARLEX SPRAYSTATION 6900

  • Page 1 EARLEX SPRAYSTATION 6900 ® OPERATING INSTRUCTION MANUAL Thank you for purchasing the Professional Earlex low pressure paint system. This highly versatile (high volume of air, low pressure painting) system can be used for a wide variey of applications. BEFORE USE - PLEASE READ THE MANUAL AND SAFETY INSTRUCTIONS.

  • Page 2: Please Read Before Use

    SAFETY OPERATING INSTRUCTIONS PLEASE READ BEFORE USE • Never under any circumstances aim the Spray Gun at another person or animal. In the event of injury occurring seek expert medical advice immediately. • The Spray Gun must only be used with paints and solvents that have a flash point suitable for spraying.

  • Page 3: Exploded Parts View

    EXPLODED PARTS VIEW Power IN Circuit Breaker (IEC Connector) 10 11 (x2) Mains Switch (230V) PARTS LIST No. Description Part No. No. Description Part No. Air Cap Ring L0151 Gland Nut L0173 Air Cap N0517 Gland Seal (2 pcs) L0168 Air Direction Plate L0162 Trigger...
  • Page 4 INTRODUCTION The concept A motor feeds out a high volume of air (HV) and enables products to be sprayed at a low pressure (LP). The product is released from the Fluid Tip of the Spray Gun at a very low pressure (0.18 bar) and is enclosed in a high volume of air.

  • Page 5: Spraying Technique

    SPRAYING TECHNIQUE Fig. 2 Round Spray Vertical Spray Horizontal Spray Horizontal and Vertical Spray Vertical and Horizontal for normal sized jobs (Fig.2) Round Spray Round for small and precise jobs The most commonly used technique for painting a wall is the ‘crisscross’ technique, i.e. you apply the product in horizontal lines and then cross over these lines by applying the product in vertical lines;...
  • Page 6 CLEANING SPRAY GUN Type of paint Cleaning Water based paint Clean with water Oiled based paint Clean with white spirit Removing the Fluid Tip and Fluid Needle assembly (for cleaning or switching to a smaller/larger diameter). Flush out the residue paint from the spray gun, as follows: Remove the paint container (25) from the spray gun.

  • Page 7: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE ACTION REQUIRED Paint too diluted Add undiluted paint The paint drips onto item being painted Paint output too high Reduce the paint output by adjusting the Fluid Adjusting Screw (12) Moving too slowly Increase speed of application Spray Trigger held for too long Release Trigger sooner Spray Gun too close...

  • Page 8: Mains Connection

    Design Registrations: GB 3022947, GB 3022948, FR 06/5463, FR 06/5462, EU 000608858, US D562,544, US D563,503 All rights reserved © 2011 EARLEX LTD. WILL ACCEPT NO RESPONSIBILITY FOR THE USE OF THIS PRODUCT IF USED FOR ANY OTHER PURPOSES THAN THOSE DETAILED HEREIN. GUARANTEE and HELPLINE This product is guaranteed for a period of 24 months against faulty manufacture or materials.
