SPRAYSTATION
HV1900
OPERATING INSTRUCTION MANUAL
Thank you for purchasing the Earlex
SprayStation kit.
®
This is a highly versatile spray kit and can be used for
a variety of applications.
BEFORE USE - PLEASE READ THE SAFETY &
OPERATING INSTRUCTIONS.
Please retain for future reference
EARLEX® LTD. WILL ACCEPT NO RESPONSIBILITY FOR THE USE OF THIS
PRODUCT IF USED FOR ANY OTHER PURPOSES THAN THOSE
DETAILED HEREIN
To register your product, please visit www.earlex.co.uk.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HV1900 and is the answer not in the manual?

Questions and answers

Related Manuals for Earlex HV1900

Summary of Contents for Earlex HV1900

  • Page 1 BEFORE USE - PLEASE READ THE SAFETY & OPERATING INSTRUCTIONS. Please retain for future reference EARLEX® LTD. WILL ACCEPT NO RESPONSIBILITY FOR THE USE OF THIS PRODUCT IF USED FOR ANY OTHER PURPOSES THAN THOSE DETAILED HEREIN To register your product, please visit www.earlex.co.uk.
  • Page 2 IMPORTANT INFORMATION (not supplied)
  • Page 3 • Use only genuine manufacturer replacement parts. • Earlex recommend the use of appropriate ear protection when using this product. • Sound pressure level: 85dB(A). • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

  • Page 4: Exploded Parts View

    Spring L0216 Paint Stirrer L1565 Fluid Adjusting Screw L0210 IF YOU HAVE ANY PROBLEMS WITH YOUR SPRAY GUN OR IF YOU BELIEVE A PART IS MISSING, DO NOT RETURN TO STORE. PLEASE CONTACT EARLEx LTD ON +44(0) 1483 454666. ®...
  • Page 5 INTRODUCTION HVLP stands for High Volume, Low Pressure. This is a type of spraying that allows you to spray extremely accurately but without all the overspray that occurs with the high pressure tank type equipment. In fact, in some parts of the world the high pressure systems are banned by law on environmental grounds and HVLP type systems are the only alternative for professional type spraying.

  • Page 6: Operation

    OPERATION Fill the paint container with the material to be sprayed. DO NOT FILL above MAX level indicator. Push the fluid tube firmly into the base of the spray gun body. Screw the container onto the gun body tightly. Place the motor unit onto a clean surface, free from any loose debris or liquids. Connect the hose to the back of the spray gun.

  • Page 7: Helpful Hints

    HELPFUL HINTS 1. Evenly control the speed of movement of the spray gun. A fast speed will give a thin coat and a slow speed will give a thick coat. 2. Stir paint well using Paint Stirrer (19). 3. Only apply one coat at a time. If a further coat is required follow the paint manufacturer’s instructions for drying times.

  • Page 8: Troubleshooting

    TURBINE UNIT The turbine unit only requires minimal maintenance. Ensure the Filter (18) is kept clean at all times. ● This can be washed out if necessary and replaced when dry. From time to time this filter will need replacing. The turbine bearings are sealed and lubricated for life.

  • Page 9: Mains Connection

    If the supply cord is damaged, it must be replaced by Earlex Ltd or our appointed agents. Your unit has been supplied with a mains lead fitted with a fuse plug. This is identified by the fuse holder in the base of the plug.
  • Page 10 NOTES...
  • Page 11 NOTES...
  • Page 12 Design Registrations: GB 3019115, US D536,706S EC Declaration of Conformity We declare that the unit HV1900 conforms to: LVD 2006/95/EC, EN60335-1, EMF EN62233; EMC 2004/108/EC, EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3. Tim Hopper Technical Director Copyright & Design Right Reserved © 2012 EARLEX LTD.
