Lightolier Calculite MBA Specification

Page 1 of 1
Catalog No.
7994 Wood Joist Mounting Bars
Features
1. Adjustment Slot: Lockable with screws.
2. Telescoping Mounting Bars: Allow fixture to be positioned anywhere
between joists spaced up to 24" on center. Can also be used on suspended
ceilings.
3. Crossbars: Allow fixture to be positioned legnthwise or crosswise to the
wood joist.
4. Nail Tab
Options & Accessories
Mounting Bars: 1950 - 18" Set of (2)
1951 - 27" Set of (2)
T-Bar Anchor Clips: 1956 - Set of (4), for use with above
Calculite ® Accessories/Options
Catalog No.
7998 Retaining Clips – Package of (2)
Features
1. Retaining Clips: 24 ga. steel with blackoxide finish.
2. Mounting Frame: Calculite ® Modular System die-cast mounting frame
(order seperately) with integral brackets attaches directly to existing ceiling
retaining clips in place of the fixture's standard mounting bars.
3. Mounting Screws: (4) for mounting on each side.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte Thomas Company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
MBA
Mounting Bars/Accessories
Type:
www.lightolier.com
