Lightolier Lytespan 6422 Specification

Page 1 of 1
11
10
6
4
5
7
Ordering Information
Catalog No. Finishes
6422MC Matte White
6423MC Matte Black
Features
1. Lytespan Attachment Fitting: Molded polycarbonate. Integral color. Fitter
twists onto track and locks on.
2. Louver: Die-cast aluminum with parallel blades for low brightness and glare
control. Matte black finish.
3. Trunnion Mounting: Permanently-tensioned with internal spring washer
and vibration-resistant nut
4. Housing: .040 aluminum.
5. Reflector: Embossed anodized clear aluminum.
6. Pivot Mounting: Permanently-tensioned; 350° stop
7. Lamp Guard: Tempered glass.
8. Yoke: Extruded aluminum
9. Push Tab: Molded polycarbonate Detaches unit
10. Polarity Keyway
11. Movable Brass Contact: Extends for connection to 2nd circuit in Advent
Lytespan Track.
Electrical
Minican screw base, No. 18 Teflon leads.
Lytespan
8
3
2-3/4"
2
Mounting Lamps
All Lytespan Track 150W T-4 Frosted (ETH)Tungsten-Halogen Minican Screw Base
System
Finish
All painted finishes are powder coated baked enamel.
Labels
UL, I.B.E.W.
Lightolier
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
® Track Lighting System
1 9
5-5/8"
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
a Genlyte Thomas Company
Horizontal Flood
5-1/2"
3-5/8"
1-7/8"
Pivot
Type:
www.lightolier.com
6422
