CycleOps 100 PRO User Manual page 3

CHAPTER 2: UnPACking THE CyClEoPs PRo sERiEs indooR CyClE
Place the box upright and cut the plastic binding straps. Lift the top of the box to expose the indoor cycle and packaging.
Remove all parts from the box including foam inserts. Ensure all the following parts are included:
Name
A Rear stabilizer
B Front stabilizer
C Main frame assembly
D Handlebar post (shorter, reads to 18")
E Seat post (longer, reads to 23")
F Seat
G Seat post clamp
H Handlebar
I Water bottle holder
J End caps
K End cap screws
L Water bottle spacer
M Large L handles
N Small L handles
O Stabilizer bolts
P Stabilizer washers
Q Multi-purpose wrench
R 6mm Allen wrench w/Phillips screw-
driver end
S 5mm Allen wrench
T 4mm Allen wrench
U 3mm Allen wrench
Additional tools that may be helpful:
-Vice Grips or small clamping tool
-17mm Cone wrench
-15mm box wrench
-10mm box wrench
-Pliers
-Pedal wrench
-2.5mm Allen wrench
Quantity
A
Rear stabilizer
1
1
1
1
1
1
1
D
Handlebar
post
1
1
2
4
18"
1
2
G
Seat post
clamp
2
8
8
1
1
J
1
End caps
1
1
M
Large L Handles
O
Stabilizer bolts
B
Front stabilizer
E
Seat post
23"
H
Handlebar
K
End cap screws
N
Small L Handles
P
Stabilizer washers
R
6mm Allen wrench w/
Phillips screwdriver end
S
5mm Allen wrench
T
4mm Allen wrench
U
3mm Allen wrench
C
Main frame assembly
F
Seat
Water bottle I
holder
L
Water bottle
spacer
Multi-purpose
Q
wrench
2
