Lightolier GUARDSMAN GV4WB332 Specification

Page 1 of 2
Features
• Excellent for locations where vandal resistance is required.
• Prismatic lens is 50% DR (impact
resistant), and 50% standard acrylic with a nominal thickness of
1/8", withstands 70 ft. lbs. impact without breaking.
• Tamper resistant holt head screws secure lens to housing.
• UL-Listed for direct mounting on low density ceilings and damp
locations.
• Steel end caps, standard.
• Self-aligning for continuous row mounting.
• Heavy duty, die formed channel of code gauge steel.
DIMENSIONS
15-5/16" (389mm)
48" (1219 mm)
2-11/16" (68mm)
1/4" x 1/2"
K.O. (2)
4' FIXTURE
VANDAL RESISTANT WRAPAROUND, 15-5/16" WIDE, 4' LENGTH
11/16" Dia.
K.O. (2)
7/8" Dia. 2-1/4" (57mm)
K.O. (3)
3-1/4" (83mm)
4-1/4" (108mm)
GUARDSMAN
SURFACE FLUORESCENT 3 LAMP, T8 OR T12
2-7/8"
(73mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
GV4WB332
Type:
www.lightolier.com
Section 6A/Folio P20-61
