Lightolier Lytecaster 2000IC Specification

Page 1 of 1
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Frame-In Kit
2000IC
Features
1. Housing: .032" aluminum. U.L. Listed for direct contact with thermal
insulation. Access door for inspection of junction box.
2. Mounting Frame: .036" (#20 ga.) galvanized steel. Accommodates all
ceilings up to 1" thick. Push-in/twist-out rotoclips hold reflector flush to
ceiling.
3. Junction Box: 4" X 3 1/2" X 2"; .063" (#14 ga.) galvanized steel. U.L. listed
for maximum of 4 No. 12 ga. 75° C through branch circuit conductors. Access
door inside of housing allows easy inspection of wiring without removal of
housing. Integral cable clamps permit attachment of nonmetallic Romex
armored cable without need of additional connectors.
4. Mounting Bars: .059" (#16 ga.) galvanized steel. 13" long bars extend
to 27" with integral nailing tabs. Attaches to wood joist without need of
accessories.
5. Socket Housing: .036" (#20 ga.) galvanized steel.
6. Socket: Porcelain medium base; nickel plated screw shell. Pre-wired with
#18 ga. SF1 leads to junction box.
7. Thermal Protector: Meets NEC and UL requirements. Located inside
housing.

Options and Accessories

Mounting Bars:
T-Bar Ceiling Clips:
Plaster Ceiling Ring:
277V Remote Step
Down Transformer:
Extra Thick Ceiling
Mounting Ring:
Lightolier is a Philips group brand
Reflector Trims — See Individual Reflector Trim Specification Sheets
Open Downlight
Aperture Cone Baffles Satin Cone
2012 2005 2008
2012NM 2005BNM 2008NM
2013 2005NM 2010
2013BKNM 2005WH 2010NM
2013BK
2013CDNM
2013CD
2013NM
2013WH
2013WD
2013WDP
1964 - 20" set of (2)
1956 - set of (4)
1959 - 7/8"depth for wet plaster ceilings
7997 - 277V down to 120V
300W max. load.
1967C
Lytecaster Recessed Downlighting
®
3 3/4" Aperture Incandescent Insulated Ceiling Frame-In Kit
Recessed
Adjustable Eyeball
2027 2022
2027BNM 2022WH
2027NM
2029WH
2029BK
2029BKNM
2029CD
2029CDNM
2029CL
2029CLNM
2029GD
2029GDNM
2027WH
Labels
UL (Suitable for Damp Locations), I.B.E.W.
or
®
Romex is a regsitered trademark is General Cable Industries Inc.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • G0711
2000IC
Frame-in Kit
Reflector Trim
Enclosed Open Wet
Diffuser Location
2090 2084WH
2084CD
Type:
