Lightolier Lytecaster 1129 Specification

Page 1 of 2
7 1/4"
1129/1104ICX/N
0
™ AirSeal ® Insulated Ceiling
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim
1129* Black Step Baffle
1129WH White Step Baffle
1129GD* Specular Gold
1129CL* Specular Clear
1129BK*
Specular Black
1129CD* Clear Diffuse
1129BNM Natural Metal Baffle
w/Natural Metal Flange
* = Add "NM" to SKU for Natural Metal™ Flange
Features
1. Reflector: Hydroformed aluminum, .040" thick; white or Natural Metal™
trim flange.
2. Aperture: Aluminum step baffle or cone, painted or anodized finish.
3. Lampholder Assembly: Die-formed steel, .060" thick; permits adjustment;
358˚ horizontal and 0˚ to 30˚ vertical.
4. Frame-In Kit: (1100IC insulated ceiling frame shown). Other frames listed
above and shown on the right. See Frame-In Kit specification sheets for more
details.
Options & Accessories
Lytegems : See 1500 Specification Sheets.
®
Retaining Clips: 1955 - For installing in existing ceiling
Extra Wide Flange Trim Ring: 1954 - 8 5/8" O.D.
Lytecaster
1129/1100IC Series
Insulated Ceiling
7 1/8"
Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Incandescent
Frame-In Kit Ceiling Type
1102P1 Non-IC
1103R Non-IC Remodeler
1100IC IC
1100AICM AirSeal IC
®
1100DICM
Deep IC
1100DAICM Deep AirSeal IC
®
1104ICX/N AirSeal IC
®
Recessed Downlighting
®
6 3/4" Aperture Recessed Adjustable Reflector Trim
7 1/8"
9 1/4"
1129/1103R
0
™ Non-IC
Remodeler Ring
Lamping
85W BR30, 90W PAR38
85W BR30, 90W PAR38
65W BR30
90W PAR38, BR40
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • H0711
1129/1102P1
Standard Incandescent
1129/1100 DEEP IC Series
Insulated Ceiling
Height
7 1/8"
7 1/8"
7 5/16"
7 5/16"
9 1/4"
9 1/4"
7 1/4"
Type:
www.lightolier.com
1129
30˚
