Lightolier Lytespan DRL35 Specification

Page 1 of 2
7 1/2"
Ordering Information
Catalog No. Finishes
dr2Ls35Wh White
dr2Ls35bk
Black
dr2Ls35sL Silver
description
Remote controlled spotlight that can be mounted anywhere along the track
and remotely aimed through the use of a hand-held controller. Can not be
dimmed. Can not turn on/off using hand-held controller.
Features
1. Full remote control of pan and tilt movement to aim at any object below
the luminaire.
2. Positions can be recorded for future use.
3. Continuous movement and sequencing option.
4. Interchangeable Click-On™ reflectors to achieve desired beam spread.
REFLECTORS SOLD SEPARATELy.
5. Die-cast aluminum housing.
Electrical
Electronic Ballast
Input Voltage: 120V, 60 Hz
Power Factor: >95%
Input Power: 44W
Max. Input Current: .37A
Total harmonic distortion: <10%
ANsI Code: M130
Do not use on a dimming circuit.
Lytespan® Track Lighting System
(190)
12 13/16"
(325)
( ) Denotes dimensions in mm
Track Mounting
Compatible with Lytespan Basic, Radius
and Advent Track Systems; and all
Multipoint and Monopoints.
DO NOT USE with Extension Wands,
Sloped Ceiling Adapter or ProSpec Track.
2 13/32"
(61)
5 1/4"
(133)
Lamp
T6 Single Ended, G12 Base
Ceramic Metal Halide 39W
Labels
cULus Classified
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • B0507
drL35
8292WE
Director Metal Halide 39W T6
® 0400
Requires Laser
Remote Control
for Operation
reflectors
Use one of:
DRT6RS
DRT6RM
DRT6RF
SOLD SEPARATELy
Type:
www.lightolier.com
