Lightolier WX4 Specification

Page 1 of 1
The WX4 Series is a corrosive environment LED Exit suitable for use in wet location areas. It offers extremely low operating costs.
(30.5 cm)
12.0"
(30.5 cm)
Complete Fixture consists of base exit.

How to Specify:

WX4
SERIES
WX4 = WX4 Wet Location
Exits

Features

1. Illumination: Illumination of the exit face is accomplished with long last-
ing, high output Light Emitting Diodes (LEDs). LEDs and support electronics
have an expected life of 25 years.
2. Housing: Constructed of fiberglass, corrosion-resistant, grey housing. Field
removable chevrons offer application flexibility.
3. Electronics: AC Only or Emergency Operation. Emergency Operation ver-
sion provides universal 120/277 VAC operation with solid-state circuitry.
Charging system is complete with low voltage disconnect, AC lockout,
brownout protection, AC indicator lamp and test switch.
4. Battery: Maintenance free, sealed lead calcium battery has an estimated
service life of 5 years, and an operating temperature range of 65°F (19°C) to
85°F (30°C).
5. Warranty: Electronics: 3 years; Battery: 1 year full, 4 years pro-rata

Code Compliance

UL 924 listed for wet locations.
National Electrical Code (NEC), NFPA70 and NFPA101 life safety codes; and
OSHA safety code illumination standards.
Lightolier is a Philips group brand
12.0"
6.9"
(17.5 cm)
1
NO. OF LETTER
FACES COLOR
1 = Single R = Red
G = Green
WX4 Series Wet Location Exit

LED Exit Suitable for Wet Locations and Corrosive Environments

OPERATION
blank = AC Only
EM = Emergency
Operation
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C0308
WX4
Type:
