Lightolier Tangent FXPDT Specification

Page 1 of 1
Ordering Information
Catalog No. Finish
FXPDT Silver
Features
1. Track Attachment fitting: Molded thermoplastic clamping adapter with
captive, nickel-plated steel pin. Clockwise rotation of pin secures fixture
adapter to track.
2. Splicing Chamber: Allows for field cutting of power cord and aircraft
cable (if applicable).
For use only with pendants that meet the following criteria:
• Total weight of all components being attached to adaptor does not
exceed 2.5 lbs.
• Pendant Cord Type is 1/4" dia. 18 ga. 3-wire, 300V min. SVT, with .062 dia.
aircraft cable, or without aircraft cable.
• Pendant is rated 120V/60Hz., .83A max, 100W max.
Tangent
1"
[27 mm]
3 3/8"
1 [84 mm]
2
Track Mountings
For use on all Tangent Track systems. For ceiling
or suspended track installation. Not for use on
wall mounted track.
™
Track Lighting System
1"
[27 mm]
3 3/8"
[84 mm]
Lamping
100W Max
Finish
All Painted finishes are baked enamel.
Accessories
No accessory capability.
Labels
cULus Listed
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • 0907
FXPDT
Pendant Adapter
Type:
www.lightolier.com
