Lightolier Lytecaster 2022 Specification

Page 1 of 2
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim
2022 Matte White w/Black Baffle
2022WH Matte White w/White Baffle
Features
1. Trim Ring: Die-formed aluminum, 0.040" thick (18 ga.). Matte white finish.
2. Eyeball Housing: Die-formed, one piece, aluminum, 0.040" thick (18 ga.).
Provides 358° horizontal rotation and 0° to 35° vertical adjustment; (0° to 30°
with 2000IC and 2000AIC). Matte white finish.
3. Frame-In Kit: See Frame-In Kit specification sheets for more details.
Lytecaster Recessed Downlighting
Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit Installation Type
2000P1 Standard Non-IC
2000IC IC
2000AIC IC Air Seal
3 3/4" Aperture Eyeball Reflector Trim
Incandescent
Lamping Height
50W PAR20 5 9/32"
75W PAR16, R20
50W PAR20, R20 5 9/32"
45W PAR16 5 9/32"
Labels
UL (Suitable for Damp Locations), I.B.E.W
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • G0711
2022
Type:
www.lightolier.com
