Installing and Configuring the QLogic QLA4010 iSCSI HBA (TOE)
4

Installing the Windows OS onto the Boot Device

4-16
EMC Fibre Channel with QLogic HBAs in the Windows Environment
17. Press
18. Press
Select Save changes, and press
19. Select Configuration Settings again, and press
20. Select iSCSI Boot Settings, and press
21. To scan for your boot port, you can press enter on the primary
boot device at the top of the Boot Settings dialog. The HBA will
scan for targets and display them. If more than one target port is
located, it will be displayed. It is helpful to know the IQN of your
target port in order to select the correct target at this point. Select
the target IQN of your target, and press
22. The HBA will display the available LUNs under the selected
target port. Select the LUN that you wish to boot from, and press
ENTER
boot LUN.
23. If you have an alternate boot target configured, repeat steps
above to select the boot LUN for the alternate boot device.
24. When all boot LUNs have been selected, press
prompted to save your changes. Once saved, the iSCSI HBA is
ready to boot from the external array. Press
Options menu to reboot the host.
Follow the appropriate steps below to install the Windows operating
copy the latest QLA4010 driver to a floppy disk for use during the
installation procedure.
1. Boot the server with Windows 2000/2003 installation CD-ROM.
The server displays the following message, followed by a blank
blue screen.
Setup is inspecting your computer's hardware configuration...
Press
Windows installer that you want to load a third-party driver
before proceeding with the installation.
2. Setup will begin loading necessary drivers for installation.
Eventually, a dialog message will tell you that the setup program
cannot determine the type of one or more mass storage devices.
to return to the Configuration Settings dialog.
ESC
again, and you will be prompted to save changes.
ESC
. You may need to use the
as soon as the blue screen appears. Pressing
F6
.
ENTER
.
ENTER
.
ENTER
.
ENTER
button to locate your
P D
AGE OWN
until you are
ESC
at the Fast!UTIL
ESC
F6
tells the
