Configuring an EMC Boot Device
3
Windows 2000

Installing EFI boot code onto the HBA

3-8
EMC Fibre Channel with QLogic HBAs in the Windows Environment
7. Some servers use SCSI CD-ROM drives. If your server has a SCSI
CD-ROM, repeat steps 5 and 6 to select the driver for the SCSI
controller. If your controller is not on the list, obtain the driver on
diskette from the vendor.
8. If you want to specify drivers for other devices installed in your
system, do so; otherwise press
dialog to continue with Windows installation.
9. After completing Windows installation, reinstall the QLogic
driver using the steps under Installation Procedure for Windows NT
Hosts on page 2-15.
For detailed installation instructions on the HP ProLiant BL20p G2
and BL40p, refer to HP ProLiant BL p-Class server blades Booting
rd
Windows systems from 3
located here:
ftp://ftp.compaq.com/pub/supportinformation/techpubs/
other/5982-3248en_rev1_us.pdf
After completing Windows installation, reinstall the QLogic driver
using the steps under Installation Procedure for Windows 2000 and
Windows 2003 Hosts on page 2-16.
To boot from a Symmetrix device via a QLogic fibre controller under
the Extensible Firmware Interface (EFI) shell, QLogic EFI boot code
must be loaded to the HBA. EFI boot code provides the ability to boot
from an attached device over Fibre Channel.
Check the EMC Support Matrix for the minimum required EFI boot
code revision.
The CD-ROM contains the latest EMC-approved EFI boot code at the
time of this document's release. Update EFI boot code files, if
available, can be found on the qLogic website
http://www.qlogic.com.
NOTE: If your system does not have a floppy disk driver, a USB pen drive
can be used to run utilities and store files for this procedure. Check with your
server vendor to determine whether a USB pen drive is supported for your
system.
at the Additional Devices
ENTER
party Storage Array Network (SAN), How To,
