Media Requirements

Preparing the Storage System

Required media includes the following:
Downloading QLogic Drivers and Firmware
Refer to
Latest EMC-approved Fibre Channel PCI HBA Driver Kit for
◆
Windows
Latest EMC-approved Fibre Channel PCI HBA firmware
◆
MS-DOS boot diskette.
◆
Boot device support requires a Navisphere Management station with
Navisphere Manager or CLI. The station must be separate from the boot
server but networked to the storage system (FC4700 and later model arrays)
or connected to the storage system (models earlier than FC4700).
Before you can install Windows onto a storage system, the storage
system must have at least one bound LUN in a Storage Group for the
boot server. The LUN must be owned by the SP connected to the boot
HBA.
For Windows NT 4.0, the host system boot LUN must be assigned Host LUN
ID 0 by the EMC storage array. (MSKB Q218974)
During this installation procedure, you should have only one LUN in
the boot Storage Group, so that you can easily identify the boot LUN.
Later, you can add other LUNs to this Storage Group.
If you need to create a LUN, refer to the EMC ControlCenter Navisphere
Management software documentation for your array type.
Configuring an EMC Boot Device
on page 2-2.
Configuring a CLARiiON Boot Device
