Lightolier Lytespan 8670WH Specification

Page 1 of 1
Catalog No. Finishes
8670WH Matte White
8670BK
Matte Black

General Description

Minimal "open back" style with ring-shaped housing supports MR16 lamp, gives
intriguing light spill from back of lamp. Provides wide range of beam spreads
from narrow to wide. Retaining springs allow fast snap-out, snap-in relamping.
May be used with a choice of accessories, including framing projector. Stem of
MR16 Ring plugs directly into any Power Jack.
Finish
All painted surfaces, baked enamel.
Electrical
Bi-pin ceramic socket pre-wired with No, 18 SF-1 leads with fiberglass braided
sleeve and silicone outer sleeve.
Lytespan Lytejacks Accent Lighting System
®
Mounting Lamps
To all Lytejacks 20W-50W
Power Jacks MR16 12V
Accessories
2" Series Color Filters and Spread Lens, Louver No. 7472
Matte Black Framing Projector 6497
(for performance data see Specification Sheet 6497).
Labels
UL; I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte Thomas Company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • B0806
8670WH
Focal Jack MR16 Ring
Type:
www.lightolier.com
8670WH
8670BK
