LPTC
8.0"
(20.32 cm)
1.1"
(2.79 cm)
1.17"
(2.97 cm)
F
LUORESCENT
Features
Illumination: Emergency
illumination is provided
to designated fluorescent
fixtures by transferring
backup generator or inverter
power to the AC ballast. The
designated emergency fixture
can be locally switched, and
will provide full-rated light
output when operating from
emergency power.
Housing: Housing and cover
are constructed of 24 gauge
galvanized steel. Low profile
housing allows mounting in
most low-profile fluorescent
fixtures with low-profile AC
ballast.
Operating Temperature
Range:
32°F (0°C) to 131°F (55°C)
LPTC Series
L
T
IGHTING
RANSFER
Electronics: 120/277 VAC
dual input voltage with all
inputs fused to 3 A.
Electrical Specifications:
(120/277 VAC) .27 mA, 1.48 W
All inputs fused to 3 A
Job Information
Type:
Job Name:
Cat. No.:
Notes:
C
IRCUIT
Page 1 of 2
Code Compliance
UL 924 "Auxiliary Power and
Lighting Equipment" listed. UL
damp location listing standard.
NFPA 101, NEC, BOCA,
OSHA and IBC illumination
standards.
Warranty
Five years full warranty.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lightolier LPTC series
Summary of Contents for Lightolier LPTC series
- Page 1 LPTC Series LUORESCENT IGHTING RANSFER IRCUIT Page 1 of 2 Features Electronics: 120/277 VAC Code Compliance LPTC Illumination: Emergency dual input voltage with all UL 924 “Auxiliary Power and illumination is provided inputs fused to 3 A. Lighting Equipment” listed. UL to designated fluorescent damp location listing standard.
- Page 2 120 V BLACK WHITE BROWN WHT/BLK WHITE/RED PROGRAMMABLE CIRCUIT BKR PANEL Philips Lightolier Job Information Type: e: lol.webmaster@philips.com t: (508) 679-8131 w: www.lightolier.com LPTC Series August 11, 2011 Specifications are subject to change without notice. © Koninklijke Philips Electronics N.V., 2011. All rights reserved.
